1. While the diagnostic test you wish to stop is running, press Escape. The Diagnostics submenu
displays.
2. On the submenu, scroll to End Curr. Test, and then press Enter. User Abort displays.
3. Press Enter to return to the Diagnostics submenu. Refer to the RMU for any test results.
To stop a test from the RMU:
1. Select the Stop Test button in the Diagnostics test section of the Error Logs and Diagnostics page.
2. Select View Status to see the results of the command. Test Stopped displays along with any test
results.
Front Panel Diagnostic Tests
You can perform the following diagnostic tests using the front panel:
Picker Test
Magazine Test
Inventory Test
Random Moves
To perform any of the front panel diagnostic tests:
1. From any menu, click the Diagnostics heading. The Diagnostics screen displays.
2. Scroll to the test you want to run and press Enter.
If you are already logged in as Administrator, the test begins executing immediately. The message
Running Test appears while the test is running.
NOTE: Each test takes from 30 seconds to several minutes to complete. To stop the test
prematurely, see " Stopping a Diagnostic Test ."
3. If you are not logged in, you will be asked to enter the Administrator password. Do the following:
From the front panel, enter the administrator password by using the Up and Down scroll
arrows to select each digit, and then press Enter to move to the next digit. To move to the
previous digit, press Escape. When you have entered the entire six digit password, you will
be asked to press Enter one more time to submit the password. If the password is incorrect,
you will be asked to re-enter it using the same procedure. Otherwise, you will be returned to
the Diagnostics menu. Press Enter to run the desired test.
Running Test appears while the test is in progress. To stop the test prematurely, see
" Stopping a Diagnostic Test ."
4. If the test is successful, press Enter to return to the Diagnostic test menu. For detailed results of a
test, use the RMU to retrieve the diagnostic test status (see " Running Diagnostic Tests ").
RMU Diagnostic Tests
Because some of the diagnostic tests require you to insert a cartridge into the autoloader, you cannot
perform these tests from a remote location. You can perform the following diagnostic tests from the RMU:
Loader - Picker Test
