80
Configuring and Managing RAID
NOTE:
You can access multiple controllers through the BIOS Configuration Utility
by pressing .
NOTE:
You can access PERC 5 and PERC 6 adapters from the same BIOS if the
PERC 5 firmware version is 5.1.1-0040 or later. You need to verify if you are currently
set to edit the PERC 5 or PERC 6 adapter.
Exiting the Configuration Utility
To exit the BIOS Configuration Utility, press at any menu screen.
If there is only one controller, then a dialog box displays to confirm your
choice. Select OK to exit and press .
If multiple controllers are present, then the key brings you to the
Controller Selection screen. Press again to reach the exit screen.
A dialog box displays to confirm your choice. Select OK to exit and press
.
Menu Navigation Controls
Table 6-1 displays the menu keys you can use to move between the different
screens in the BIOS Configuration Utility.
Table 6-1. Menu Navigation Keys
Notation Meaning and Use Example
Use the right arrow key to open a submenu, move
from a menu heading to the first submenu, or move
to the first item in that submenu. If you press the
right arrow key at a menu heading, the submenu
expands. Press it again to go to the first item in the
submenu. The right arrow key is also used to close a
menu list in a popup window. Word wrap is
supported. Start
Programs
Use the left arrow key to close a submenu, move
from a menu item to the menu heading for that
item, or move from a submenu to a higher level
menu. If you press the left arrow key at a menu
heading, the submenu collapses. Press it again to go
to the higher-level menu. Word wrap is supported. Controller 0
Disk Group 1
