Toggles microprocessor speeds on 101-key keyboard (in MS-DOS® real
mode only)
Toggles microprocessor speeds on 102-key keyboard (in MS-DOS real mode
only)
Starts the System Setup program (during power-on system test [POST] only)
Automatically starts (boots) the system from the network environment
specified by the Managed Boot Agent (MBA) rather than from one of the
devices in the
Launches the utility partition (if installed) during system start-up
Controls and Indicators
Reset control
No reset button on small-form-factor systems
Power control
Push button
Power indicators
Green light-emitting diode (LED) on riser board; blinking green in sleep state;
dual-color LED on front panel—green for power, yellow for diagnostics
Hard-disk drive access
indicator
Green LED
Link integrity indicator (on
NIC connector)
Green LED for 10-Mb operation; orange LED for 100-Mb operation
Activity indicator (on NIC
connector)
Yellow LED
Power
DC power supply:
Wattage
Small-form-factor chassis: 110
Heat dissipation
Small-form-factor chassis: 808 British thermal units (BTU)/hr (nominal)
Voltage
90 to 135 volts (V) at 60 Hz; 180 to 265 V at 50 Hz
Backup battery
3-V CR2032 coin cell
