b57udiag -mba
Enables/disables Multi-Boot Agent (MBA) protocol.
1 = Enable
0 = Disable
b57udiag -mbap
Selects the specific MBA protocol.
0 = Preboot Execution Environment (PXE)
1 = Remote Program Load (RPL)
2 = Bootstrap Protocol (BOOTP)
b57udiag -mbas
Selects the MBA speed and duplex mode.
0 = Auto
1 = 10 Mbps speed, half-duplex operation
2 = 10 Mbps speed, full-duplex operation
3 = 100 Mbps speed, half-duplex operation
4 = 100 Mbps speed, full-duplex operation
6 = 1000 Mbps speed, full-duplex (fiber)
b57udiag -firm
Updates the EEPROM of the selected adapter based on the match between the existing image file name
and the new image .
Examples:
b57udiag -firm ee5751c3.40a
b57udiag -firm ee5721c3.40a
b57udiag -firmall
Updates the EEPROM of all of the adapters based on the image match.
b57udiag -ver Displays the version of the software/eeprom.bin file.
b57udiag -pxe
Loads the Preboot Execution Environment (PXE) firmware from a file.
Example:
b57udiag -pxe b57mmba.nic
Note: This command should be used only for add-in adapters. For LOM adapters, the PXE firmware is
loaded automatically during startup.
b57udiag -elog
Prints the error log to a file.
b57udiag -help Displays this table of MS-DOS Command Prompt Mode Command Options.
Running in Broadcom Command Line Interface Mode
At the MS-DOS prompt, type b57udiag -cmd, and use the command options as shown in Table 2
NOTE: The values for settings are in decimal notation unless otherwise indicated.
Table 2: Broadcom Command Line Interface (CLI) Mode Commands
Command Description
upgfrm
Updates the PXE or Boot Code from a file
dir Displays the file directory in NVRAM.
setwol
Enables/disables the Wake on LAN (WOL) property.
setwol -e
= Enable WOL
setwol -d
= Disable WOL
setpxe
Enables/disables Preboot Exchange Environment (PXE) and sets PXE speed
setpxe -e
= Enable PXE
setpxe -d
= Disable PXE
setpxe -s 0
= Auto (Default)
setpxe -s 1
= 10 Mbps speed, half-duplex operation
setpxe -s 2
= 10 Mbps speed, full-duplex operation
setpxe -s 3
= 100 Mbps speed, half-duplex operation
setpxe -s 4
= 100 Mbps speed, full-duplex operation
setman
Enable/Disable Management Firmware.
setman -e
= Enable Management Firmware
setman -d
= Disable Management Firmware
setman -q
= Query Management Firmware Enable State
setman -t
= Toggle Active APE Mgmt Firmware
Enables/disables Multi Boot Agent (MBA) and selects the MBA protocol
setmba -d
= Disable MBA
setmba -e 0
= Enable Preboot Execution Environment (PXE) MBA (default)
setmba -e 1
= Enable Remote Program Load (RPL) MBA
