9
Table 10 — Configuration Mode and Sub-Mode Directory (cont)
SUB-MODE
KEYPAD
ENTRY
ITEM DISPLAY
ITEM
EXPANSION
COMMENT
OPT1 UNIT OPTIONS 1 HARDWARE
FLUD X COOLER FLUID
Default: Water
1 = Water
2 = Medium Temperature Brine
MLV.S YES/NO MINIMUM LOAD VALVE SELECT Default: No
R.G.EN ENBL/DSBL RETURN GAS SENSOR ENABLE
OAT.E ENBL/DSBL ENABLE OAT SENSOR
D.G.EN ENBL/DSBL DISCHARGE GAS TEMP ENABLE
CSB.E ENBL/DSBL CSB BOARDS ENABLE
CPC ON/OFF COOLER PUMP CONTROL Default: On
PM.DY XX MIN COOLER PUMP SHUTDOWN DLY 0 to 10 minutes, Default: 1 min.
DPME x ENABLE CONDENSER PUMP 0 to 2
DFLS ENBL/DSBL ENABLE COND FLOW SWITCH
CDWS ENBL/DSBL ENABLE COND WTR SENSORS
OPT2 UNIT OPTIONS 2 CONTROLS
CTRL X CONTROL METHOD Default: Switch
0 = Enable/Off/Remote Switch
2 = Occupancy
3 = CCN Control
LCWT XX.X F HIGH LCW ALERT LIMIT
Default: 60
Range: 2 to 60 F
DELY XX MINUTES OFF TIME
Default: 0 Minutes
Range: 0 to 15 Minutes
ICE.M ENBL/DSBL ICE MODE ENABLE Default: Disable
CCN CCN NETWORK CONFIGURATION
CCNA XXX CCN ADDRESS
Default: 1
Range: 1 to 239
CCNB XXX CCN BUS NUMBER
Default: 0
Range: 0 to 239
BAUD X CCN BAUD RATE Default: 9600
1 = 2400
2 = 4800
3 = 9600
4 = 19,200
5 = 38,400
RSET RESET COOL TEMP
CRST X COOLING RESET TYPE Default: No Reset
0 = No Reset
1 = 4 to 20 mA Input
2 = Outdoor Air Temperature
3 = Return Fluid
4 = Space Temperature
MA.DG XX.X F 4-20 - DEGREES RESET
Default: 0.0 F
Range: –30 to 30 F
RM.NO XXX.X F REMOTE - NO RESET TEMP
Default: 125 F (51.7C)
Range: 0° to 125 F
RM.F XXX.X F REMOTE - FULL RESET TEMP
Default: 0.0 F (-17.8C)
Range: 0  to 125F
RM.DG XX.X F REMOTE - DEGREES RESET
Default: 0.0 F
Range: –30 to 30 F
RT.NO XXX.X F RETURN - NO RESET TEMP
Default: 10.0 F (5.6C)
Range: 0  to 125F COOLER T
RT.F XXX.X F RETURN - FULL RESET TEMP
Default: 0.0 F (0.0C)
Range: 0  to 125F COOLER T
RT.DG XX.X F RETURN - DEGREES RESET
Default: 0.0 F
Range: –30 to 30 F (–34.4 to -1.1 C)
DMDC X DEMAND LIMIT SELECT Default: None
0 = None
1 = Switch
2 = 4 to 20 mA Input
3 = CCN Loadshed
DM20 XXX % DEMAND LIMIT AT 20 MA
Default: 100%
Range: 0 to 100%
SHNM XXX LOADSHED GROUP NUMBER
Default: 0
Range: 0 to 99
SHDL XXX % LOADSHED DEMAND DELTA
Default: 0%
Range: 0 to 60%
SHTM XXX MAXIMUM LOADSHED TIME
Default: 60 minutes
Range: 0 to 120 minutes
DLS1 XXX % DEMAND LIMIT SWITCH 1
Default: 80%
Range: 0 to 100%
DLS2 XXX % DEMAND LIMIT SWITCH 2
Default: 50%
Range: 0 to 100%
ENTER
ENTER
ENTER
ENTER
