Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Catalog No. 04-53190018-01

Printed in U.S.A.

Form 19/23-2SI

Pg 1

6-11

Replaces: 19/23-1SI

Installation and Start-Up Instructions

Part No: 33CNTVIEW

CONTENTS

SAFETY CONSIDERATIONS

. . . . . . . . . . . . . . . . . . . . . . 1

INTRODUCTION

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

ABBREVIATIONS AND EXPLANATIONS

. . . . . . . . . . 1

PACKAGE CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . 1

CHILLER SOFTWARE VERSION
REQUIREMENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1,2

INSTALLATION

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Equipment Needed

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Step 1 — Identify Power Supply

. . . . . . . . . . . . . . . . . . 2

Step 2 — Assemble Swing Arm

. . . . . . . . . . . . . . . . . . 2

Step 3 — Attach Arm to Tube Sheet

. . . . . . . . . . . . . . 2

Step 4 — Mount Display Screen on Arm

Mounting Bracket

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Step 5 — Connect Cable Between Display and

ICVC (International Chiller Visual Control)

. . . . . . 4

START-UP

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Start Touch Screen System

. . . . . . . . . . . . . . . . . . . . . . 4

Start Carrier Network Manager

. . . . . . . . . . . . . . . . . . . 5

Configure ComfortVIEW™ Software on Touch

Screen

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

SAFETY CONSIDERATIONS

When installing this accessory, observe precautions in the

literature and on any labels attached to the equipment, and all

other safety precautions that may apply.
• Follow all safety codes.
• Use care in handling and installing this accessory.

INTRODUCTION

Carrier's new EverVu™ touch screen display allows a facil-

ity manager to monitor a chiller from a 15-in. color touch

screen display. The EverVu display screens allow easy naviga-

tion to determine data and chiller trends such as a chiller per-

formance trend, chilled water trend, condenser water trend and

power trend. The EverVu touch screen display is available for

Evergreen 19XR, 19XRV and 23XRV chillers and 32 Series

chiller retrofit packages. The display is provided with Comfort-

VIEW™ software preloaded.

Retrofit Compatibility —

The EverVu™ display can

be retrofitted to any existing Carrier Comfort Network

®

(CCN)

compatible chiller, though default screen sets may not be

included for all chillers. The display may also be retrofitted to

competitor’s chillers when the 32 Series retrofit panels are

applied.

ABBREVIATIONS AND EXPLANATIONS

Terms and abbreviations used in this manual include:

PACKAGE CONTENTS

• Touch screen display screen with quick connect mount

• Swing arm for mounting (assembly required; see Swing

Arm Assembly Instructions)

• RS-232 to RS-485 converter from B&B Electronics

• ComfortVIEW software key (USB) (already installed in

back side of display screen)

• Several bags containing bolts and Allen style wrenches

• Touch computer power supply

• 6-ft or 25-ft Beldon power cable (25-ft cable will be

available for order)

• 25-ft coiled communication cable with RJ-14 connectors

• Swing Arm Assembly Instructions

CHILLER SOFTWARE VERSION REQUIRE-

MENTS

The chiller software in the International Chiller Visual Con-

trol (ICVC) controller must match a version of chiller software

for which the EverVu workspace screens have been developed.

The EverVu display is supplied with databases to support the

chiller software versions listed in Table 1.

Table 1 — Chiller Software Version Requirements

WARNING

Electrical shock can cause personal injury and death. Shut

off all power to this equipment during installation. There

may be more than one disconnect switch. Tag all discon-

nect locations to alert others not to restore power until work

is completed.

CCN (Carrier
Comfort Network)

— Carrier’s proprietary communications

protocol

CCN bus

— 3-wire RS-485 network for CCN elements

CCN element

— Unique addressing scheme for devices

on a CCN network

Network Manager

— ComfortVIEW software system for

managing network devices

Workspace
Manager

— ComfortVIEW software for managing

viewspaces and trends within
workspaces for graphical representation
of a system

UNIT

EVERVU DATABASE

VERSION

CHILLER

SOFTWARE

VERSION

19XR

19XR Version 09 Chiller

CESR-131294-09

19XRV

19XRV Version 04 Chiller

CESR-131350-04

23XRV

23XRV Version 02 Chiller

CESR-131293-02

32DK

19DK Version 01 Chiller
(Build 0.016)

CESR-131458-01

32XR

32XR Version 01 Chiller

CESR-131435-01

EVERVU™ Touch Screen Display for

EVERGREEN

®

19XR,XRV, 23XRV Chillers

with PIC II or PIC III Controls
