A-4 ADS RainAlert II Manual
Voltage Regulator 13.5 VDC maximum input
A/D Conversion 12 bit, 8 channel, 500KHz sample rate
Tipping Buckets (ADS p/n 103202A/B/C/D)
The following table contains the specifications for the 8-inch
tipping bucket (without a heater).
Note: Some specifications may vary for ADS-supplied
tipping buckets of other sizes.
Housing Industrial grade PVC
Funnel/Legs Anodized aluminum
Dimensions 12 inches high x 8 inches in diameter
Weight 8 pounds
Switch Magnetic proximity reed; encapsulated in
hermetically-sealed glass tube; 10 watts, 200
VDC
Minimum
Resolution
0.01 inches (.25 mm) per tip
Maximum Tips
Per Second
10
Accuracy +/- 2% at 1 inch per hour
Minimum Alarm
Threshold
0.01 inches (.25 mm) per 5 minutes
Cable Standard size: 20 feet long x 0.29 inches
diameter OD polyurethane jacket
Extension cables available up to 300 feet
