A-1
A P P E N D I X A
Specifications
This appendix contains specifications for the ADS

RainAlert II

monitor, printed circuit board, tipping buckets, and lightning
protection module.
ADS RainAlert II Monitor (p/n 6000-RAW/RAL)
The following table contains the specifications for the RainAlert II
monitor.
Note: RainAlert II monitors are not intrinsically safe.
Enclosure Stahlin “J” series HPL (hinged, padlock latch)
enclosure; NEMA Type 4X 6P hot compression
molded fiberglass reinforced polyester (thermoset)
with stainless steel hardware
Dimensions External: 13.56 inches high x 11.43 inches wide x
5.21 inches deep
Internal: 11.79 inches high x 9.80 inches wide x 4.94
inches deep
Mounting: 12.75 top-to-bottom x 8.00 right-to-left
Mounting hole diameter: 0.31 inches
Weight 22 pounds (monitor with battery)
