Great Plains YP1625 Operator Manual - Manual (Page 43)

7/12/2005 401-182M
41 Adjustments
Changing Seed Meters
To change from Precision Meter to Finger
Pickup Meter
1.
Clean out meter. For more information see
“Cleaning Out Meters,” page 59.
Refer to Figure 41
2. Twist the seed hose to align the tabs with the
slots in the meter opening and remove hose.
Refer to Figure 42
3. Disengage the drive coupler by pulling out on
the pin, twisting it a quarter turn and resting it
in the shallow slot.
Refer to Figure 43
4. Release the lower latch.
21909
21968
21969
21914
Figure 41
Figure 42
Figure 43
