CCM Status Code
Group 3 -- Gas Controller Status & Protocol
Code Message Remedy / Comments
301 Not used Reserved for other models.
302 Reserved No information available; Contact customer service
303
Gas Supply Pressure
out of range.
PAK 200i is in SET mode or Plasma gas pressure is too low; Defective gas pressure
sensor (PS1).
304 Gas Control Purging Normal following power up or returning from Plasma Disable.
305 Not used Reserved for other models.
306 Not used Reserved for other future use.
307 Not used Reserved for other models.
308
Gas Control Type
Mismatch
Wrong CCM, must be PAK 200i type.
309 Not used Reserved for other models.
310 Not used Reserved for other models.
311 Not used Reserved for other models.
312 Not used Reserved for other models.
313 Not used Reserved for other models.
CCM Status Code
Group 4 -- Torch Coolant System
Code Message Remedy / Comments
401 Coolant Level low Check coolant level, add as needed.
402
Low coolant flow
Coolant flow as measured by flow switch FS1 is less than 0.5 gpm; Clogged filter;
Restriction in torch lead or head; Wrong style consumables; broken or defective torch
coolant tube/check valve; Defective pump or bypass valve.
403
Coolant overheated Coolant supply temperature exceeded 75 degrees Celcius (167F). Operating with either
lower side panel loose or removed; Coolant fan failed; radiator fins clogged with dirt.
404
Coolant System not
ready.
Proper coolant flow of 0.5 gpm as measured by flow switch FS1 was not obtained dur-
ing up to 4 minutes of Priming. New installation can require additional Priming cycle(s)
to fill hoses with coolant; cylce power to restart Priming; Coolant hoses or torch hoses
reversed; Clogged coolant filter; Restriction in torch lead or head; Wrong style consum-
ables; broken or defective torch coolant tube/check valve; Defective pump or bypass
valve.
405
Low Coolant Level
Warning
Low coolant level during cut, does not stop cut.
Add coolant as required.
406 Not used Reserved for other models.
407
Coolant overheated, high
ambient.
Ambient greater than 40 deg C results in coolant overheating. Reduce cutting duty cycle;
Reduce ambient; Add separate cooler.
NOTE
There are no 500 codes
