PAK 200i
2-2 SPECIFICATIONS Manual 0-5335
2.05 Power Supply Specifications & Electrical Requirements
PAK 200i 380V Power Supply Specifications
Max OCV (U0) 400 vdc
Max Output Current 200 Amps
Output Voltage 60 - 160 vdc
Duty Cycle Rating 100% @ 200A @ 200V (40 kW)
Operating range 14°F to 122°F (-10°C to + 50°C)
Power Factor 0.94 @ 200 ADC Output
Cooling Forced Air (Class F) and Liquid Cooled
PAK 200i 400V Power Supply Specifications
Max OCV (U0) 425 vdc
Max Output Current 200 Amps
Output Voltage 60 - 160 vdc
Duty Cycle Rating 100% @ 200A @ 200V (40 kW)
Operating range 14°F to 122°F (-10°C to + 50°C)
Power Factor 0.94 @ 200 ADC Output
Cooling Forced Air (Class F) and Liquid Cooled
PAK 200i 480V Power Supply Specifications
Max OCV (U0) 425 vdc
Max Output Current 200 Amps
Output Voltage 60 - 160 vdc
Duty Cycle Rating 100% @ 200A @ 160V (32 kW)
Operating range 14°F to 122°F (-10°C to + 50°C)
Power Factor 0.94 @ 200 ADC Output
Cooling Forced Air (Class F) and Liquid Cooled
PAK 200i Power Supply
Input Suggested Sizes (See Note)
Voltage Freq.
Power
(3-Ph)
Current
(3-Ph)
Fuse
(Amps)
Wire (AWG) Wire (mm 2 )
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
380 50/60 39 60 100 #6 16
400 50/60 39 57 100 #6 16
480 50/60 39 47 90-100 #8 10
* Suggested wire size based on United States NFPA 70 National Electrical
Code 2011 edition published by the National Fire Prevention Association. List-
ings are from table 400.5(A)(2) for flexible cord of certain types rated for 75
deg C in ambient temperatures up to 30 deg C. Using wires of lower tempera-
ture rating or different insulation type may require larger wire size. Derate for
higher ambient.
These are suggestions only. Always refer to your local and national codes that
apply to your region for final determination of correct wire type and size.
CAUTION
Fuse and wire sizes are for reference only. The installation must conform to national and local codes for the type
and method of wire being used.
