nFORCE™ LED Lightbar
nForce Lightbar 05.14
IMPORTANT
WHEN PASSING CABLES THROUGH FIREWALL OR OTHER
SHEETMETAL, INSERT GROMMET TO PROTECT THE CABLE!
!
WARNING
Route wires only in locations that are not subjected to
potential wear. Make sure to avoid routing wires in the
deployment area of your air bag. Refer to your vehicle’s
owner’s manual for airbag deployment zone.
ELECTRICAL INSTALLATION (CONTINUED)
Stop / Tail / Turn (STT) Light Configuration:
a. Apply voltage to Ignition Input Wire and then set Switch #2 on Breakout box to down position (Switch #1 must be in Up position)
b. Determine which module inputs are needed for Stop / Tail / Turn Lights
c. Apply voltage to the Left Turn or Right Turn activation wires
d. Apply voltage to the light group wire(s) required (i.e. Rear Inboard 1, Rear Inboard 2, etc.)
e. Momentarily apply voltage to the pattern select wire to change the color between Off, Color 1, Color 2, and Color 3.
NOTE: If configuring a single color or dual color module, make sure the chosen color is configured for Off and not a color which does not
exist on the module. The light-bar will flash color #1 of all modules configured for STT function. If a module flashes every 2 seconds and
is not intended to be on when an STT function is activated, repeat steps ‘d’ and ‘e’ until module no longer flashes.
f. Set Switch #2 on Breakout box to up position to save settings and return light-bar to normal operating mode
Cruise Mode Configuration:
a. Apply voltage to Ignition Input Wire and then set Switch #2 on Breakout box to down position (Switch #1 must be in Up position)
b. Determine which module inputs are needed for cruise mode
c. Apply voltage to the Cruise Mode activation wire
d. Apply voltage to the light group wire(s) required (i.e. Front Corner, Front Inboard 1, etc.)
e. Momentarily apply voltage to the pattern select wire to change the color between Off, Color 1, Color 2, and Color 3.
NOTE: If configuring a single color or dual color module, make sure the chosen color is configured for Off and not a color
which does not exist on the module. The lightbar will flash color #1 of all modules configured for cruise mode. If a module
flashes every 2 seconds and is not intended to be on when Cruise mode is activated, repeat steps ‘d’ and ‘e’ until module no
longer flashes.
f. Set Switch #2 on Breakout box to up position to save settings and return light-bar to normal operating mode
