nLINE RUNNING LIGHT

#ENL172(x)-L - 72” LEFT WIRE EXIT
#ENL172(x)-R - 72” RIGHT WIRE EXIT
#ENL160(x)-L - 60” LEFT WIRE EXIT
#ENL160(x)-R - 60” RIGHT WIRE EXIT
#ENL148(x)-L - 48” LEFT WIRE EXIT
#ENL148(x)-R - 48” RIGHT WIRE EXIT
#ENL136(x)-L - 36” LEFT WIRE EXIT
#ENL136(x)-R - 36” RIGHT WIRE EXIT

nLINE Running Board Lites 7.14

Pg. 1

1.800.338.7337 / www.soundoffsignal.com

IMPORTANT INFORMATION:

Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances. These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these devices to ensure compliance.

To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at

www.soundoffsignal.com/sales-support.

If you have questions regarding this product, contact

Technical Services, Monday - Friday, 8 a.m. to 5 p.m. at 1.800338.7337 (press #4 to skip the automated message).

Questions or comments that do not require immediate attention may be emailed to

[email protected].

SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.

• Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances.
These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these
devices to ensure compliance.
• DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to your vehicle
Owner’s Manual for the location of any air bag deployment zones.
• DO NOT connect this device to a strobe power supply. This product is self-contained and does not
require an external power supply.

Important Information:

!

WARNING

This product contains high intensity LED devices. To

prevent eye damage, DO NOT stare into the light

beam at close range.

INSTALLATION:

1. Establish a position on the bottom of the

running board on the left or right side of

your vehicle.

2. Use the screw holes on the running board

as a template to mark locations of screw

access holes.

3. Use a 5/16” diameter drill for the wire holes

4. Size pilot holes for mounting screws

appropriately.

5. Fasten light using mounting

screws (NOT SUPPLIED).

WIRE HOOK-UP TABLE

WIRE COLOR:

CONNECT TO:

RED

+Vdc

BLACK

Ground (-)

WHITE

Pattern Select/Sync

GREEN

Simultaneous or

Alternate

PATTERN SELECT

1. With light powered, touch White wire to
Red Power wire for 1 second.

PATTERN RESET

1. With light powered, touch White wire to
Red wire for 3 seconds.
2. Remove White wire from power. Pattern
resets to 1.

SYNC MULTIPLE LIGHTS

1. Set up all lights to the same pattern
2. Connect White wires of all lights to sync

together.

a. Note, only 6 lights can be synced

together.

b. Insulate connections
3. Green Wire Connection
a. For Simultaneous Flashing of a group of

lights:

i. Connect all Green wires together of

the group of lights desired to flash in

unison.

ii. All Green wires connected together

form one light group

b. For alternating flashing of a group of

lights:

i. Connect one group of Green wires

to Power (+Vdc)

ii. These lights will flash in unison.

iii. Connect one group of Green wires

together but leave floating.

iv. These lights will flash in unison.

v. Together, both light groups will

alternate.

vi. For two lights simply connect one

Green wire to Power (+Vdc) and

leave the other Green wire floating.

vii. Insulate connections.

Tech Specs

nLINE Strip Light

Flash Patterns:

10 Flash Patterns

Light Sync:

Yes

Mounting:

Surface Mount

Input Voltage:

10 - 16 Vdc

Dimensions:

Width x Height x Depth

72” W x 2.25” H x .75” D
60” W x 2.25” H x .75” D
48” W x 2.25” H x .75” D
36” W x 2.25” H x .75” D

Operating Temp.:

-40° to +65° C

Flash Patterns

Pattern Name

F.P.M.

(Flashes / Minute)

1. Quint

70

2. Warp**

350

3. Double Flash**

70

4. Quad

80

5. Power Pulse

180

6. Road Runner

113

7. Quad 2

68

8. Double 2

95

9. Chase 1

117

10. Chase 2**

70

Strip Lights have 3, 4, 5 or 6 segments depending on length. These segments alternate

flashing patterns 1-8 (odd segments flashing together & even segments flashing together.

**Does not meet SAE Standard
