IMPORTANT INFORMATION:
Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances. These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these devices to ensure compliance.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at
www.soundoffsignal.com/sales-support.
If you have questions regarding this product, contact
Technical Services, Monday - Friday, 8 a.m. to 5 p.m. at 1.800.338.7337 (press #4 to skip the automated message).
Questions or comments that do not require immediate attention may be emailed to
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
• Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances.
These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these
devices to ensure compliance.
• DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to your vehicle
Owner’s Manual for the location of any air bag deployment zones.
• DO NOT connect this device to a strobe power supply. This product is self-contained and does not
require an external power supply.
EGHST1(xx)-12 7.14
Important Information:
OPERATION:
WIRE CONNECTIONS
See setup procedure on second page.
The single GHOST comes equipped with
an internal flasher with 33 user selectable
patterns that can be synchronized either
alternating or simultaneous with up to three
other lights. It can also be put into slave
mode and driven through an external flasher.
1. Connect the GHOST BLACK wire to a
good, convenient ground.
2. Connect the GHOST RED wire to one side
of a user supplied on/off switch. Connect the
other side of the switch, through a 5Amp
fuse, to a source of +10-16Vdc.
NOTE:
The GHOST is a factory sealed unit that
CANNOT be serviced in the field. Any
attempt to gain access to the GHOST unit
will most likely cause permanent damage
and void its warranty.
INSTALLATION:
1. Screw Mount
Establish a position on the vehicle. Use
the mounting slots as a template to mark
hole locations. Drill a hole using a #27 drill
bit. The Torx screws provided are self-
tapping.
Loosen the two #10 TORX screws on
the back of each housing to adjust the angle
of the GHOST. After adjustment, tighten the
TORX screws.
2. Adhesive Mount
To obtain optimum adhesion, the bonding
surfaces must be well unified, clean and dry.
Peel one side of each adhesive mounting
patch provided. Apply each rectangular
patch to the bottom of the GHOST housing.
Positon the GHOST on the vehicle and mark
2 edges of the location using tape. Peel the
remaining paper from the adhesive patch
and carefully position the light using the
tape template. Press down on housing firmly
to insure good adhesive contact. Important:
Apply carefully; adjustment is not possible
after the adhesive bonds. Ultimate strength
of adhesive is achieved after 24 hours.
Loosen the two #10 TORX screws on
the back of each housing to adjust the angle
of the GHOST. After adjustment, tighten the
TORX screws.
3. New ‘U’ bracket for mounting on hood or
trunk edge.
Open the hood or trunk that will be the
attachment surface. Place the rubber pad
provided on the surface, insuring that the
lower lip is on the edge of the sheet metal.
Fit the ‘U’ bracket to the back of the GHOST
light base, nesting the bracket holes with
the pins on thelight base. Slide the assembly
onto the rubber pad. Tighten the four set
screws.
Loosen the two #10 TORX screws on
the back of each housing to adjust the angle
of the GHOST. After adjustment, tighten the
TORX screws.
This product contains high
intensity LED devices. To prevent
eye damage, DO NOT stare into
light beam at close range.
WARNING
!
TECHNICAL SPECIFICATIONS
Overall Dimensions:
4”L x 0.88”H x
1.75”D
Input Voltage Range:
10-16Vdc
Current Consumption: 0.75 Amps /module*
Light Sync Technology
Yes
Operating Temperature:
-20º to +65º C
# of Flash Patterns
33
*Pattern Dependent
Screw Mount
Adhesive Mount
‘U’ bracket
Supplied #10 thread forming screw.
Hole with #27 drill
Supplied #10-24 3/8” lg. hex
drive set screw
GHOST® DUAL MULTI-MOUNT LIGHT
EGHST1(x)-12 - Black
EGHST1(x)W-12 - White
