nFORCE™ LED Lightbar
nForce Lightbar 05.14
ELECTRICAL INSTALLATION (CONTINUED)
Warning Flash Pattern Configuration:
a. Apply voltage to Ignition Input Wire and then set Switch #2 on Breakout box to down position (Switch #1 must be in Up position)
b. Apply voltage to the activation wire of the function which requires pattern to be changed (i.e. Front Corner, Takedown, Left Alley, etc.)
c. Apply voltage to the Mode activation wire to configure mode 2 flash patterns, leave Mode activation wire floating to configure mode 1 flash patterns
d. Momentarily apply voltage to the pattern select wire to change the warning flash pattern
e. Set Switch #2 on Breakout box to up position to save settings and return light-bar to normal operating mode
NOTE: Takedown and Alley light patterns are limited to pattern #1 – 11
7.
*fpm=Flashes per Minute
**fps=Flashes per Second
FLASH PATTERNS
#
Name
SAE
Compliant
Timing
Color
Sequence
fpm
fps
1
Random Single #1
Yes
#1
Variable
-
-
2
Random Single #2
No
#1
Variable
-
-
3
Quint
Yes
#1
Alternating
70
1.2
4
Quad 2
Yes
#1
Variable
-
-
5
Q-Switch
Yes
#1
Variable
-
-
6
Double
Yes
#1
Alternating
115
1.9
7
Power Pulse
Yes
#1
Alternating
180
3.0
8
RoadRunner
Yes
#1
Alternating
115
1.9
9
SlowRunner
Yes
#1
Alternating
70
1.2
10
Warp
No
#1
Alternating
350
5.8
11
Inter-cycle
No
#1
Alternating
-
-
12
Warp 1, 2, 3
No
#1
Variable
-
-
13
E-Single
Yes
#1
Alternating
125
2.1
14
E-Double
Yes
#1
Alternating
125
2.1
15
E-Triple
Yes
#1
Alternating
125
2.1
16
Random Dual #1
Yes
#1/2
Variable
-
-
17
Random Dual #2
No
#1/2
Variable
-
-
18
Quint Dual
Yes
#1/2
Alternating
70
1.2
19
Quad 2 Dual
Yes
#1/2
Variable
-
-
20
Q-Switch Dual
No
#1/2
Variable
-
-
21
Double Dual
Yes
#1/2
Alternating
115
1.9
22
Power Pulse
Yes
#1/2
Alternating
180
3.0
23
RoadRunner Dual
Yes
#1/2
Alternating
115
1.9
24
SlowRunner Dual
Yes
#1/2
Alternating
70
1.2
25
Warp Dual
No
#1/2
Alternating
350
5.8
26
Inter-cycle Dual
No
#1/2
Alternating
-
-
27
Warp 1, 2, 3, Dual
No
#1/2
Variable
-
-
28
Dual Color Flash 1
No
#1/2
Variable
-
-
29
Dual Color Flash 2
No
#1/2
Variable
-
-
30
Impact
No
#1/2
Variable
-
-
31
Explosion
No
#1/2
Variable
-
-
32
Tri Color Flash 1
No
#1/2/3
Alternating
-
-
ARROW PATTERNS
#
Name
SAE
Compliant
Timing
Color
Sequence
fpm fps
1
Single Fast
No
-
-
-
-
2
Single Slow
No
-
-
-
-
3
Chaser Fast
No
-
-
-
-
4
Chaser Slow
No
-
-
-
-
5
Fill Fast
No
-
-
-
-
6
Fill Slow
No
-
-
-
-
