32 E-flite PT-19 ARF Assembly Manual
 2. Insert the leadout guide into the notch in the
wing tip as shown.
 3. Check to make sure the leadout wires are not
crossed between the fuselage and leadout guide.
If so, remove the guide and rotate it so the wires
do not cross then insert it back into the slot in the
wing tip.
 4. The leadout guide is attached to the wing using
a #4 washer and 4-40 lock nut. Use a 1/4-inch
nut driver to tighten the nut. Make sure not to over-
tighten the nut and crush the wing structure.
 5. Use a 3/32 ball driver to open the tip weight
box under the right wing tip. Insert 3/4 oz of
weight into the box for the first control line flights.
We use three Sig lead balancing weights (1/4 oz
each) inside the box to laterally balance the model
for control line flying.
In higher wind conditions you might find that 4
lead weights work better. This is a personal flight
preference. For new CL pilots we recommend 4
weights in high wind environments (5–10 mph).
