E-flite PT-19 450 ARF - Manual (Page 12)

12 E-flite PT-19 ARF Assembly Manual
 9. Apply epoxy in the joiner pocket and root of the
remaining wing panel.
 10. Slide the wing panels tightly together. Remove
the T-pin from the joiner that was installed in Step
4. Slide the wing panels tightly together. Again,
work slowly to clean up any excess epoxy using a
paper towel and rubbing alcohol.
 11. Use low-tack tape to hold the two wing panels
together until the epoxy fully cures. Clean any
excess epoxy from the wing panels using rubbing
alcohol and a paper towel.
You can use the two 4-40 x 1-inch socket head
wing bolts and three rubber bands to hold the wings
together while the epoxy cures. Simply insert the wing
bolts half-way into the holes at the trailing edge and
wrap a rubber band around the bolts on both the
top and bottom of the wing. Use a third rubber band
around the wing dowels. Always clean up any excess
epoxy using a paper towel and rubbing alcohol.
