3 E-flite PT-19 ARF Assembly Manual
Recommended Radio Equipment,
Radio Controlled Version
You will need a minimum of a 4-channel transmitter,
receiver and four servos. You can choose to purchase
a complete radio system. If you are using an
existing transmitter, just purchase the other required
equipment separately. We recommend the crystal-
free, interference-free Spektrum ™ DX5e 2.4GHz DSM ®
5-channel system. If using your own transmitter, we
recommend the E-flite S75 Sub-Micro servos.
If you own a Spektrum radio, just add a DSM2 ™
receiver and four E-flite S75 Sub-Micro servos. We
show the installation of the AR6100 receiver in the
manual.
Radio System
SPM5500 DX5e DSM2 5CH system
Or Purchase Separately
any of the Following Receivers
SPMAR500 AR500 DSM2 5-Channel Full-
Range Receiver (for DX5e, DX6i
or DX7)
SPMAR6100 AR6100 DSM2 6-Channel Park
Flyer Receiver (for DX5e, DX6i,
or DX7)
SPMAR6100E AR6100E DSM2 6-Channel Park
Flyer Receiver (for DX5e, DX6i,
or DX7)
SPMAR6200 AR6200 DSM2 6-Channel Full
Range Receiver (for DX5e, DX6i,
or DX7)
And
EFLRS75 7.5-gram Sub-Micro
Servo (4)
EFLREX6L 6-inch Extension, Lightweight (2)
EFLRYH3 3-inch Y-harness, Lightweight
Recommended Equipment,
Control Line Version
EFLA170 Control Line Handle
EFLA171 52’ Braided Steel Lines
EFLA172 Control Line Motor Timer
SIGSH561 Sig Mfg Lead Balancing
Weight (1/4 ounce)
Optional Accessories
EFLA110 Power Meter
EFLC3005 Celectra ™ 1- to 3-Cell
Li-Po Charger
EFLC505 Intelligent 1- to 5-Cell
Balancing Charger
EFLA150 Military Pilot (1 or 2)
Brushless Outrunner Setup
EFLM1400 Park 450 Brushless Outrunner
Motor, 890Kv
APC10070E 10x7 Electric Propeller
EFLP1080E 10X8 Electric Propeller
EFLA1030 30-Amp Pro Switch-Mode
BEC Brushless ESC
or
EFLM1505 Park 480 Brushless Outrunner
Motor, 1020Kv
APC12060E 12x6 Electric Propeller
EFLA1040L 40-Amp Lite Pro Switch-Mode
BEC Brushless
and
EFLA172 Motor Timer (control line only)
EFLB21003S 2100mAh 3S 11.1V 20C Li-Po,
13AWG EC3
Required Tools and Adhesives
Tools & Equipment
Card stock Epoxy brushes
Low-tack tape Medium grit sandpaper
Mixing cups Mixing sticks
Paper towels Pencil
Pin drill Pliers
Rubbing alcohol Ruler
Scissors Square
String/dental floss T-pins
Trim seal tool Phillips screwdriver: #0, #1
Felt-tipped pen Rubber bands (optional)
Heat gun Sealing iron
Hobby knife (#11 blade)
Nut driver: 1/4-inch, 5.5mm
Hex wrench or ball driver: 1.5mm, 3/32-inch
Drill bit: 1/16-inch (1.5mm), 1/8-inch (3mm)
Adhesives
Threadlock 30-Minute Epoxy (HAN8002)
Thin CA 6-Minute Epoxy (HAN8000)
Note on Lithium Polymer Batteries
Lithium Polymer batteries are significantly
more volatile than alkaline or Ni-Cd/
Ni-MH batteries used in RC applications.
All manufacturer’s instructions and warnings
must be followed closely. Mishandling of
Li-Po batteries can result in fire. Always
follow the manufacturer’s instructions when
disposing of Lithium Polymer batteries.
