INSTALLATION
INSTRUCTIONS
9530 & 9531 Instructions 1-14-13.doc Page 2 of 16
Install Mirror
5. Remove the mirror bridge wiring cover by gripping
each side with your fingers, sliding upwards, and
pulling down. (Figure 1)
Figure 1
6. Remove the mirror harness connector from the back
of the mirror by pulling it out with your fingers.
(Figure 2)
Figure 2
7. Remove the screw that attaches the existing rear
view mirror to the windshield mounting tab with a
T20 Torx driver. (Figure 3)
Figure 3
8. Slide mirror upwards and towards the rear to
remove it from windshield.
9. Remove light cover from the overhead console by
using a pick to pop the front off and then sliding the
rear tabs out of their slots. (Figure 4)
Figure 4
10. Remove one screw on each side of the overhead
console. (Figure 5)
Figure 5
11. Remove the overhead console by starting at the
front and pulling rearward with your hands to
release the mounting clips. (Figure 6)
Figure 6
