Rockwell Automation Publication GMC-RM009D-EN-P - June 2014 97
Kinetix 5500 Drive Systems
Bulletin MPAI Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance Specifications with Ball Screw Electric Cylinders
Performance Specifications with Roller Screw Electric Cylinders
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Electric Cylinder
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk System Peak
Stall Force
N (lb) Motor Output
Power Rating
kW
Kinetix 5500 Drives
(480V AC input)
25 °C (77 °F) 40 °C (104 °F)
MPAI-B2076CV1
305 (12)
0.90 890 (200) 706 (159) 2.30
1446 (325)
0.22
2198-H003-ERS x MPAI-B2150CV3
1.29 1446 (325) 1147 (258) 3.25 0.25
MPAI-B2300CV3
MPAI-B3076CM1 305 (12)
1.35
1624 (365) 1290 (290)
4.57
4448 (1000)
0.27 2198-H008-ERS x
MPAI-B3076EM1 610 (24) 814 (183) 645 (145) 2570 (578)
MPAI-B3150CM3
279 (11)
2.81
4003 (900) 3176 (714) 4.30 4448 (1000)
0.39
2198-H008-ERS x MPAI-B3300CM3
MPAI-B3450CM3 188 (7.3)
MPAI-B3150EM3
559 (22)
2002 (450) 1588 (357) 7.07 4003 (900) 2198-H008-ERS x MPAI-B3300EM3
MPAI-B3450EM3 376 (15)
MPAI-B4150CM3
279 (11)
5.61
7784 (1750) 6179 (1389) 8.68 8896 (2000)
0.43
2198-H015-ERS x MPAI-B4300CM3
MPAI-B4450CM3 245 (9.5)
MPAI-B4150EM3
559 (22)
3892 (875) 3092 (695) 14.14 7784 (1750) 2198-H015-ERS x MPAI-B4300EM3
MPAI-B4450EM3 491 (19)
MPAI-B5
xxxCM3
200 (7.8)
6.62
13,123 (2950) 10,415 (2341) 8.48 13,345 (3000)
0.55 2198-H015-ERS x
MPAI-B5 xxxEM3 400 (15.6) 6562 (1475) 5208 (1171) 16.70 13,122 (2950)
Electric Cylinder
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk System Peak
Stall Force
N (lb) Motor Output
Power Rating
kW
Kinetix 5500 Drives
(480V AC input)
25 °C (77 °F) 40 °C (104 °F)
MPAI-B3076RM1 305 (12)
1.45
1557 (350) 1237 (278)
4.57
4862 (1093)
0.27 2198-H008-ERS x
MPAI-B3076SM1 610 (24) 778 (175) 618 (139) 2431 (547)
MPAI-B3150RM3
279 (11)
2.81
3781 (850) 3003 (675)
7.07
7562 (1700)
0.39 2198-H008-ERS
x
MPAI-B3300RM3
MPAI-B3450RM3 176 (6.9)
MPAI-B3150SM3
559 (22)
1891 (425) 1499 (337) 3781 (850) MPAI-B3300SM3
MPAI-B3450SM3 353 (14)
MPAI-B4150RM3
279 (11)
5.61
7340 (1650) 5827 (1310)
14.14
14,679 (3300)
0.43 2198-H015-ERS x
MPAI-B4300RM3
MPAI-B4450RM3 196 (7.6)
MPAI-B4150SM3
559 (22)
3670 (825) 2914 (655) 7340 (1650) MPAI-B4300SM3
MPAI-B4450SM3 393 (15)
