Kinetix 5500 Drive Systems
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient, and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Bulletin VPF Motor Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Rotary Motor
Rated Speed,
max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Speed at Motor
Rated Output
rpm
Kinetix 5500 Drives
(240V AC Input)
VPF-A0632F
4800
2.55
0.93 (8.0)
8.75
2.69 (24.0)
0.36 (0.48)
4800
2198-H008-ERS
x
VPF-A0633C
3000
2.50
1.27 (11.0)
8.75
4.09 (36.0)
0.37 (0.50)
3000
2198-H008-ERS
x
VPF-A0633F
4500
3.52
1.27 (11.0)
8.80
2.87 (25.0)
0.47 (0.63)
4500
2198-H008-ERS
x
12.60
4.09 (36.0)
2198-H015-ERS
x
VPF-A0752C
3300
3.80
1.61 (14.0)
13.30
4.39 (39.0)
0.49 (0.66)
3300
2198-H015-ERS
x
VPF-A0752E
4800
4.90
1.61 (14.0)
17.70
4.10 (36.0)
0.63 (0.84)
4800
2198-H015-ERS
x
18.90
4.39 (39.0)
2198-H025-ERS
x
VPF-A0753C
3300
4.09
2.16 (19.0)
17.70
6.55 (58.0)
0.59 (0.79)
3300
2198-H015-ERS
x
18.90
7.02 (62.0)
2198-H025-ERS
x
VPF-A0753E
4600
6.12
2.28 (20.0)
17.70
5.13 (45.0)
0.76 (1.02)
4600
2198-H015-ERS
x
25.34
7.35 (65.0)
2198-H025-ERS
x
VPF-A1001C
2800
3.61
1.93 (17.0)
8.80
3.22 (28.0)
0.56 (0.75)
2800
2198-H008-ERS
x
10.38
3.78 (33.0)
2198-H015-ERS
x
VPF-A1001M
6500
7.15
1.95 (17.0)
17.70
3.31 (29.0)
1.29 (1.73)
6500
2198-H015-ERS
x
20.20
3.78 (33.0)
2198-H025-ERS
x
VPF-A1002C
3000
6.24
3.39 (30.0)
17.70
6.80 (60.0)
1.03 (1.38)
3000
2198-H015-ERS
x
20.33
7.82 (69.0)
2198-H025-ERS
x
VPF-A1002F
5000
10.04
3.26 (29.0)
28.30
6.77 (60.0)
1.60 (2.14)
5000
2198-H025-ERS
x
34.30
7.82 (69.0)
2198-H040-ERS
x
VPF-A1003C
2250
6.14
4.18 (37.0)
17.70
9.76 (86.0)
0.83 (1.11)
2250
2198-H015-ERS
x
20.20
11.15 (99.0)
2198-H025-ERS
x
VPF-A1003E
3750
9.58
4.18 (37.0)
28.30
9.76 (86.0)
1.25 (1.67)
3750
2198-H025-ERS
x
28.80
11.15 (99.0)
2198-H040-ERS
x
VPF-A1003F
5500
15.62
4.18 (37.0)
45.90
10.25 (90.0)
1.81 (2.42)
5500
2198-H040-ERS
x
50.0
11.15 (99.0)
2198-H070-ERS
x
VPF-A1153C
2300
8.88
6.50 (58.0)
28.30
18.30 (162)
1.16 (1.56)
2300
2198-H025-ERS
x
33.0
20.33 (180)
2198-H040-ERS
x
VPF-A1303B
1950
10.34
8.80 (78.0)
28.30
19.85 (175)
1.53 (2.05)
1950
2198-H025-ERS
x
31.0
20.72 (183)
2198-H040-ERS
x
VPF-A1303F
4000
18.60
7.75 (69.0)
45.90
15.36 (136)
2.25 (3.02)
4000
2198-H040-ERS
x
62.0
20.72 (183)
2198-H070-ERS
x
VPF-A1304A
1600
9.43
10.29 (91.0)
28.30
25.03 (221)
1.47 (1.98)
1600
2198-H025-ERS
x
33.76
28.45 (252)
2198-H040-ERS
x
VPF-A1304D
3000
18.40
10.20 (90.0)
45.90
21.48 (190)
1.98 (2.65)
3000
2198-H040-ERS
x
58.0
27.10 (240)
2198-H070-ERS
x
