Kinetix 5500 Drive Systems
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Kinetix 5500 Drives/MP-Series Electric Cylinder Curves
Electric Cylinder
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak Stall
Current
Amps 0-pk
System Peak Stall
Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(480V AC input)
MPAR-B1
xxxB
150
1.15
240 (53.9)
1.35
300 (67.4)
0.036
2198-H003-ERS
x
MPAR-B1
xxxE
500
1.49
280 (62.9)
1.71
350 (78.7)
0.140
2198-H003-ERS
x
MPAR-B2
xxxC
250
1.67
420 (94.4)
1.90
525 (118)
0.105
2198-H003-ERS
x
MPAR-B2
xxxF
640
3.29
640 (144)
3.93
800 (180)
0.410
2198-H008-ERS
x
MPAR-B3
xxxE
500
5.16
2000 (450)
6.17
2500 (562)
1.00
2198-H015-ERS
x
MPAR-B3
xxxH
1000
6.13
1300 (292)
6.79
1625 (365)
1.30
2198-H015-ERS
x
500
400
300
200
100
0
112
89.9
67.4
45.0
22.5
0
Velocity (mm/s)
150
100
0
200
50
2198-H003-ERSx and MPAR-A1xxxB-VxA
2198-H003-ERSx and MPAR-B1xxxB-VxA
Force
(N)
Force
(lb)
500
400
300
200
100
0
112
89.9
67.4
45.0
22.5
0
2198-H008-ERSx and MPAR-A1xxxE-VxA
2198-H003-ERSx and MPAR-B1xxxE-VxA
Force
(N)
Force
(lb)
Velocity (mm/s)
100
400
300
0
600
500
200
2198-H008-ERSx and MPAR-A2xxxC-VxA
2198-H003-ERSx and MPAR-B2xxxC-VxA
Force
(N)
Force
(lb)
Velocity (mm/s)
50
200
150
0
300
250
100
22.5
45.0
67.4
89.9
112
135
0
100
200
300
400
500
600
700
157
0
1000
800
600
400
200
0
Velocity (mm/s)
600
400
0
800
200
2198-H015-ERSx and MPAR-A2xxxF-VxA
2198-H008-ERSx and MPAR-B2xxxF-VxA
Force
(N)
Force
(lb)
225
180
135
89.9
45.0
0
500
300
700
100
= Intermittent operating region
= Continuous operating region
