Rockwell Automation Publication GMC-RM009D-EN-P - June 2014
63
Kinetix 5500 Drive Systems
Kinetix 5500 (400V-class operation) Drives with MP-Series Food Grade Motors
This section provides system combination information for the Kinetix 5500 drives (with 480V, nominal input) when
matched with MP-Series (400V-class) food-grade motors. Included are motor power/brake and feedback cable catalog
numbers, system performance specifications, and the optimum torque/speed curves.
Bulletin MPF Motor Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Motor Power/Brake and Feedback Cables Overview beginning on
Motor-end connector kits are available for motor power/brake and feedback cables. Refer to the Kinetix Motion Accessories Technical Data, publica
, for more information.
Cable length
xx is in meters. Refer to the Kinetix Motion Accessories Technical Data, publica
, for standard cable lengths.
Bulletin MPF Motor Performance Specifications with Kinetix 5500 (400V-class operation) Drives
IMPORTANT
These motors require the 2198-H2DCK feedback converter kit.
Motor Cat. No. (400V-class)
Motor Power/Brake Cable
Motor Feedback Cable
(1)
(1) Use the 2198-H2DCK Hiperface-to-DSL converter kit with flying-lead cables on the drive end. Refer to Required Drive Accessories on
.
MPF-B310P, MPF-B320P, MPF-B330P
2090-CP
xM7DF-16AAxx (standard, non-flex)
2090-CP
xM7DF-16AFxx (continuous-flex)
2090-CFBM7DF-CEAA
xx (standard, non-flex)
2090-CFBM7DF-CEAF
xx (continuous-flex)
Absolute High-resolution Feedback
MPF-B430P
MPF-B4530K, MPF-B4540F
MPF-B540K
2090-CP
xM7DF-10AAxx (standard, non-flex)
2090-CP
xM7DF-10AFxx (continuous-flex)
Rotary Motor
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5500 Drives
(480V AC operation)
MPF-B310P
5000
2.30
1.60 (14)
7.10
3.6 (32)
0.77
2198-H008-ERS
x
MPF-B320P
5000
4.24
3.10 (27)
14.0
7.8 (69)
1.5
2198-H015-ERS
x
MPF-B330P
5000
5.70
4.18 (37)
17.7
10.4 (92.0)
1.6
2198-H015-ERS
x
19.0
11.1 (98)
2198-H025-ERS
x
MPF-B430P
5000
9.20
6.55 (58)
28.3
17.6 (156)
2.0
2198-H025-ERS
x
32.0
19.8 (175)
2198-H040-ERS
x
MPF-B4530K
4000
9.90
8.25 (73)
28.3
18.7 (165)
2.4
2198-H025-ERS
x
31.0
20.3 (179)
2198-H040-ERS
x
MPF-B4540F
3000
9.10
10.20 (90)
28.3
26.2 (232)
2.5
2198-H025-ERS
x
29.0
27.1 (240)
2198-H040-ERS
x
MPF-B540K
4000
20.5
19.4 (171)
60.0
48.6 (430)
4.1
2198-H070-ERS
x
