Kinetix 5500 Drive Systems
Kinetix 5500 (400V-class operation) Drives with Kinetix VP Low Inertia Motors
This section provides system combination information for the Kinetix 5500 drives (with 480V, nominal input) when
matched with Kinetix VP (400V-class) low-inertia motors. Single cable catalog numbers, system performance
specifications, and the optimum torque/speed curves are included.
Bulletin VPL Motor Cable Combinations
Motor Cat. No. (400V-class) Feedback Type Single Cable Cat. No.
(1)
(1) Cable length
xx is in meters, 01 (3.3)…50 (164) in 1.0 m (3.3 ft) increments. Refer to the Kinetix Motion Accessories Technical Data, publication
GMC-TD004 , for cable specifications.
For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Single Motor Cable Overview beginning on page 11 .
VPL-B063
xx
Multi-turn or Single-turn
Digital Encoder Feedback
2090-CSBM1DF-18AA xx or
2090-CSWM1DF-18AA
xx (standard, non-flex)
2090-CSBM1DF-18AF xx (continuous-flex)
VPL-B0751M, VPL-B0752E, VPL-B0752F, VPL-B0753E, VPL-B0753F
VPL-B1001M
, VPL-B1002E,
VPL-B1003C
VPL-B0752M, VPL-B0753M 2090-CSBM1DF-14AA xx or
2090-CSWM1DF-14AA
xx (standard, non-flex)
2090-CSBM1DF-14AF
xx (continuous-flex) VPL-B1002M, VPL-B1003F, VPL-B1003T
VPL-B1152C
2090-CSBM1DF-18AA
xx or
2090-CSWM1DF-18AA xx (standard, non-flex)
2090-CSBM1DF-18AF
xx (continuous-flex)
VPL-B1152F, VPL-B1152T, VPL-B1153E, VPL-B1153F
2090-CSBM1DF-14AA
xx or
2090-CSWM1DF-14AA
xx (standard, non-flex)
2090-CSBM1DF-14AF xx (continuous-flex)
VPL-B1303
x, VPL-B1304x, VPL-B1306x
VPL-B1651C, VPL-B1651F, VPL-B1652C, VPL-B1652F, VPL-B1653C, VPL-B1653D, VPL-B1654B
VPL-B1654D 2090-CSBM1DF-10AF xx (continuous-flex)
Bulletin VPL Motor Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Motor Cat. No.
Rated Speed,
max
rpm System Continuous
Stall Current
A (0-pk) System Continuous
Stall Torque
N•m (lb•in) System Peak
Stall Current
A 0-pk System Peak
Stall Torque
N•m (lb•in) Motor Rated
Output
kW (Hp) Speed at Motor
Rated Output
rpm
Kinetix 5500 Drives
(480V AC input)
VPL-B0631T 8000 1.20 0.46 (4.0)
3.50 1.12 (10.0)
0.31 (0.42) 8000
2198-H003-ERS
x
4.20 1.33 (12.0) 2198-H008-ERS x
VPL-B0631U 8000 1.92 0.46 (4.0) 6.48 1.33 (12.0) 0.31 (0.42) 8000 2198-H008-ERS x
VPL-B0632F 4600 1.20 0.93 (8.0)
3.50 2.26 (20.0)
0.37 (0.50) 4600
2198-H003-ERS x
4.20 2.69 (24.0) 2198-H008-ERS x
VPL-B0632T 8000 2.55 0.93 (8.0) 8.75 2.69 (24.0) 0.54 (0.72) 8000 2198-H008-ERS
x
VPL-B0633M 6700 2.50 1.27 (11.0) 8.75 4.09 (36.0) 0.57 (0.76) 6700 2198-H008-ERS x
VPL-B0633T 8000 3.52 1.27 (11.0)
8.80 2.87 (25.0)
0.57 (0.76) 8000
2198-H008-ERS x
12.60 4.09 (36.0) 2198-H015-ERS x
VPL-B0751M 8000 2.90 1.01 (9.0)
8.80 2.20 (19.0)
0.54 (0.72) 8000
2198-H008-ERS x
9.12 2.27 (20.0) 2198-H015-ERS x
VPL-B0752E 4900 2.70 1.61 (14.0)
8.80 4.10 (36.0)
0.67 (0.90) 4900
2198-H008-ERS x
9.45 4.39 (39.0) 2198-H015-ERS x
VPL-B0752F 7000 3.80 1.61 (14.0) 13.30 4.39 (39.0) 0.80 (1.07) 7000 2198-H015-ERS x
VPL-B0752M 8000 4.90 1.61 (14.0)
17.70 4.10 (36.0)
0.81 (1.09) 8000
2198-H015-ERS x
18.90 4.39 (39.0) 2198-H025-ERS
x
VPL-B0753E 4500 3.80 2.28 (20.0) 13.30 7.35 (65.0) 0.81 (1.09) 4500 2198-H015-ERS x
