Table AĆ4. Isolation Transformer Specifications (Continued).
HP
kVA
Primary Vac
Secondary
Vac
Reliance Part
Number
2
5.0
230/460
230
77530Ć16G
575
230
77530Ć17G
3Ć5
10.0
230/460
230
77530Ć16H
575
230
77530Ć17H
NOTE: Smaller drives through 3/4 HP @ 115 VAC and 2.0 HP @ 230 VAC may be used with permanent magnetic field motors, and those drive
models are supplied without a DĆC field supply.
Table AĆ5. Fuse Requirements.
Dual Element Class
K5, RK5, 250VAC Fuse
HP
AĆC Line
Volts
Quantity
AMP
Reliance Part
Number
1/4Ć3/4
115
1
1
15
64676Ć1W
1/2Ć1 1/2
230
2
15
64676Ć1W
2Ć3
230
2
30
64676Ć1Z
5
230
2
50
64676Ć1AD
1
Install fuse in input line L1 (hot line).
Table AĆ6. Controller Modification Kits.
Kit Name
Kit Model
Number
Controller
Modification
?
1
Options Required
Instruction
Manual
Local Operator Station Faceplate
14C201 thru 8
no
None
-
Blank Operator Station
Faceplates
14C200
no
Reliance Remote Operator Control Station
-
Remote Operator Adapter Kit
14C220
yes
(See Blank Faceplate, just above.)
-
Double Pole Circuit Breaker
14C210 thru 13
yes
None
-
Auxiliary Mounting Bracket
2
14C209
no
Always used with some other option; inĆ
cluded with Field Supply Kit.
-
Reversing Contactor
14C217 &
14C218
yes
FORWARD/REVERSE selector switch on
Operator Station (See table 6.B.)
D2Ć3307
Auxiliary MContact
14C219
no
Auxiliary Mounting Bracket
2
-
Tachometer Feedback
14C221
yes
None
DĆ3969
Voltage/Tachometer Follower
14C223
yes
May need AUTO/MANUAL selector switch
DĆ3971
Torque Taper
14C224
yes
None
-
Test Meter Adapter
14C225
no
None
DĆ3970
Automatic Reversing
14C226
no
Auxiliary Mounting Bracket
Reversing Contactor Kit
-
Dynamic Braking
14C214 thru 16
no
None
-
Instrument Interface/
Preset Speed
14C222
yes
If preset speed only, may need AUTO/
ąăMANUAL switch.
If follows process controller, may need
ąăAUTO/MANUAL switch.
DĆ3967
Master Isolated Reference
Receiver
14C229
yes
Master Isolated Reference Transmitter
-
Dancer Follower
14C230
yes
None
DĆ3966
1
Modification here means that some work such as jumper placement, resistor clipping, or wiring reconnection must be performed.
