2:6
Table 2Ć3. Fuse Requirements.
Dual Element Class
K5, RK5, 250VAC Fuse
HP
AĆC Line
Volts Quantity AMP
Reliance Part
Number
1/4Ć3/4 115 1 1 15 64676Ć1W
1/2Ć1 1/2 230 2 15 64676Ć1W
2Ć3 230 2 30 64676Ć1Z
5 230 2 50 64676Ć1AD
1 Install fuse in input line L1 (hot line).
Table 2Ć4. Controller Modification Kits.
Kit Name
Kit Model
Number
Controller
Modification
? 1 Options Required
Instruction
Manual
Local Operator Station Faceplate 14C201 thru 8 no None -
Blank Operator Station
Faceplates
14C200 no Reliance Remote Operator Control Station -
Remote Operator Adapter Kit 14C220 yes (See Blank Faceplate, just above.) -
Double Pole Circuit Breaker 14C210 thru 13 yes None -
Auxiliary Mounting Bracket 2 14C209 no
Always used with some other option; inĆ
cluded with Field Supply Kit.
-
Reversing Contactor
14C217 &
14C218
yes
FORWARD/REVERSE selector switch on
Operator Station (See table 2Ć1A.)
D2Ć3307
Auxiliary M Contact 14C219 no Auxiliary Mounting Bracket -
Tachometer Feedback 14C221 yes None DĆ3969
Voltage/Tachometer Follower 14C223 yes May need AUTO/MANUAL selector switch DĆ3971
Torque Taper 14C224 yes None -
Test Meter Adapter 14C225 no None DĆ3970
Automatic Reversing 14C226 no
Auxiliary Mounting Bracket
Reversing Contactor Kit
-
Dynamic Braking 14C214 thru 16 no None -
Instrument Interface/
Preset Speed
14C222 yes
If preset speed only, may need AUTO/
ąăMANUAL switch.
If follows process controller, may need
ąăAUTO/MANUAL switch.
DĆ3967
Master Isolated Reference
Receiver
14C229 yes Master Isolated Reference Transmitter -
Dancer Follower 14C230 yes None DĆ3966
1 Modification here means that some work such as jumper placement, resistor clipping, or wiring reconnection must be performed.
