Page 50
A:3
Table AĆ2. Local Operator Control Faceplates
Specify
Operator's
Functions Provided
1
When UsingA
MinPak Plus
Controller With:
Operator's
Control
Faceplate
Model
Start/
Stop
SpeedĆ
setting
Pot
TorqueĆ
setting
Pot
Run/
Jog
Selector
Forward/
Reverse
Selector
Automatic/
Manual
Selector
BasicFeatures Plus Torque
Control and Automatic/
Manual Modes of OperaĆ
tion
14C207
yes
yes
yes
yes
no
yes
BasicFeatures Plus ArmaĆ
tureĆReversing, Torque
Control and Automatic/
Manual Modes of OperaĆ
tion
14C208
yes
yes
yes
yes
yes
yes
Table AĆ3. Remote Operator Control Stations
When UsingA
MinPak Plus
Controller With:
Specify
Operator's
Station Model
Start/Stop
Rocker Switch
Speed Setting
Potentiometer
Run/Jog
Selector
Forward/
Reverse
Selector
BasicFeatures (Standard
Unidirectional Station)
9C45
yes
yes
yes
no
NEMA type 4 Station with
BasicFeatures
9C18
yes
yes
yes
no
ExplosionĆProof Station with
BasicFeatures
9C17
yes
yes
yes
no
BasicFeatures Plus Armature
Reversing (Standard
Reversing Station)
9C46
yes
yes
yes
yes
NEMA Type 4 Station for
Reversing
9C19
yes
yes
yes
yes
ExplosionĆProof Station for
Reversing
9C16
yes
yes
yes
yes
Table AĆ4. Isolation Transformer Specifications.
HP
kVA
Primary Vac
Secondary
Vac
Reliance Part
Number
1/4
0.5
230/460
115
77530Ć16A
0.5
575
115
77530Ć17A
1/3
0.75
230/460
115
77530Ć16B
0.75
575
115
77530Ć17B
1/2Ć3/4
1.5
115
115
77530Ć15D
230/460
115
77530Ć16D
575
115
77530Ć17D
230/460
230
77530Ć16D
575
230
77530Ć17D
1
2.0
230/460
230
77530Ć16E
575
230
77530Ć17E
1Ć1 1/2
3.0
230/460
230
77530Ć16F
575
230
77530Ć17F
