Configuring SLC500 Applications
6-1
C
HAPTER
6
Configuring SLC500 Applications
Chapter 6 describes how to configure a SLC500 PLC on a ControlNet network with a
GV 3000 drive.
Both the 1747-SCNR and 1747-KFC15 modules are required to communicate fully
with a drive and both must be configured as drops on the ControlNet network. If the
application only calls for access to Drive Reference and Feedback Data (such as Drive
Control and Status Words), and does not call for access to any N10, N11, or N12 drive
parameters, the 1747-KFC card will not be required. However, Unscheduled
Messaging will not be possible and another connection option to the processor will be
required for downloading the required ladder logic.
This chapter is intended for use by personnel familiar with the installation and
operation of the Reliance Drive and the installation, programming, I/O configuration
and operation of the SLC processor using RSLinx, RSLogix 5000 and RSNetWorx for
ControlNet software. Personnel should also be familiar with the system configuration
documentation.
6.1
Required Software and Equipment
Software and equipment required for configuring a SLC500 on a ControlNet network
is listed in table 6.1.
6.2
Network Configuration
Configure the ControlNet network using RSLinx and RSNetWorx for ControlNet
software.
Table 6.1 – Required Software and Equipment
Equipment Description
Version
RSLinx Software
Version 2.20 or later
RSNetWorx for ControlNet software
Version 2.25 or later
RSLogix 500 software
Version 3.01 or later
SLC 500 Chassis w/appropriately sized Power Supply
SLC 5/03 processor (1747-L532)
or SLC 5/04 processor
OS 301 or higher
Any OS
ControlNet Scanner Module: 1747-SCNR
ControlNet RS-232 Interface: 1747-KFC15
PC with 1784-KXTC15 or 1784-PCIC interface card
GV3000 ControlNet Communications Board (2CN3000)
Version 2.20 or later
