Rockwell Automation GV3000/SE AC Drive ControlNet Network Communication Board, M/N 2CN3000 User Manual
Page 53

Installation
2-41
2.9
Connecting the GV3000/SE Drive to a
ControlNet Network
The ControlNet network is composed of:
•
trunk cables
•
drop cables (run from a tap on the trunk cable to a node)
•
taps
•
terminators
•
repeaters
Refer to your ControlNet Network Planning and Installation manual for a detailed
description of how to install a ControlNet network and add a drop to an existing
ControlNet network.
Step 4.1 Stop any application tasks that are running.
Step 4.2 Remove the lockout and tag. Apply power to the drive. SELF is displayed
while the drive performs power-up diagnostics. If there is an error during
diagnostics, it is logged. See your drive software manual for information on
errors.
Step 4.3 Connect a ControlNet Network drop cable to one of the BNC connectors on
the option board. Connect the other end to a tap.
See figure 2.21 for cabling and termination connections.
!
ATTENTION: Do not let any metallic surfaces on the BNC connectors,
plugs, or optional accessories touch grounded metallic surfaces. This
contact could cause noise on the network. Failure to follow this precaution
could result in damage to equipment.
