Rockwell Automation Publication 6155R-UM002E-EN-P - February 2014 47
Appendix
A
Specifications
The following tables contain specifications for the 200R compact non-display
computers. For additional specifications, go to
http://ab.rockwellautomation.com/Computers .
Table 2 - Hardware and Software Specifications
Table 3 - Power Specifications
Specifications Attribute
6155F-NPXP, 6155F-NPXPDC, 6155F-NPWE, 6155F-NPWEDC,
6155R-NSXP, 6155R-NPXP, 6155R-NPXPDC
Hardware Display Requires an external display
Processor Intel Celeron M, 1 GHz
RAM
Standard
Performance 1 GB (2 GB max)
2 GB (2 GB max)
Drive
6155F
6155R 32 GB, 2.5 in. SLC™ solid-state drive
100 GB rotating hard-disk drive
CompactFlash 2 CompactFlash Type II card slots (one internal, one external)
I/O ports • Serial port (1 port for standard, 2 ports for performance)
• 1 PS/2 keyboard port
• 1 PS/2 mouse port
• 4 USB 2.0 ports
• 1 VGA port
• 1 audio line-out
Ethernet LAN port (RJ-45)
Performance
Standard Two 10/100/1000 Mbps LAN ports
One 10/100/1000 Mbps LAN port
Software Operating systems Windows XP Professional, Service Pack 3
Windows Embedded Standard 2009
Attribute
6155F-NPXP, 6155F-NPXPDC, 6155F-NPWE, 6155F-NPWEDC, 6155R-NSXP,
6155R-NPXP, 6155R-NPXPDC
Input voltage, AC 100…240V, autoranging
Line frequency 47…63 Hz
Power consumption, AC 35 W (0.64 A @ 100V rms, 0.37 A @ 240V rms)
64VA @ 100V, 88.8VA @ 240V
Input voltage, DC 9…36V
Power consumption, DC 35 W (3.89 A @ 9V, 0.97 A @ 36V)
Power management ACPI compliant
