Page 37: Memory configuration guidelines upgrade the memory
Rockwell Automation Publication 6155R-UM002E-EN-P - February 2014
37
Component Replacement
Chapter 4
Replace or Upgrade the
Memory Module
The computer’s motherboard has one dual-channel DDR-II SO-DIMM slot that
supports up to 2 GB maximum system memory.
Memory Configuration Guidelines
Follow these guidelines when replacing or upgrading memory to the computers.
· Use only standard unbuffered memory modules that conform to both
PC2-5300 and SPD compliance industry standards.
· Use only DDR-II type memory modules.
· Use only memory modules with gold-plated contacts.
· Always handle a memory module by its edges.
Upgrade the Memory
Follow these steps to upgrade the memory.
1. Follow the steps for
2. Remove the bottom plate as detailed in
IMPORTANT
We recommend that you use only Allen-Bradley approved memory
modules. Refer to
for
qualified replacement parts and accessories.
IMPORTANT
Use an antistatic wrist strap connected to the work surface, and properly
grounded tools and equipment.
