3Ć19

9.40

(239)

7.55

(192)

SIDE VIEW

FRONT VIEW

DIMENSIONS IN INCHES (MM)

MOUNTING DETAILS

5.50

(140)

TOP VIEW

5.50

(140)
5.00

(127)

.25 (6)

1.00 (25)

9.00

(229)

7.00

(178)

.22 x .36

SLOT

Figure 3.17 Ć Mounting Dimensions
