Chapter 2
Introduction to the DL40
2 – 12
Use one of the Allen-Bradley Ethernet computer interface boards (or its
equivalent) for PassThrough file transfers.
•
Catalog Number 6628-A5
•
Catalog Number 6628-A7
DL40 Message Displays are available with varying amounts of memory in
either two- or four-line versions.
Table 2.G
Product Identification and Catalog Numbers
Description Memory Size
Remote I/O
Communication Version
Catalog Number
Parallel Communication
Port Versions Catalog
Number
Two Line Display 16 K Message
Memory
2706–E23J16B1 2706–E23J16
Two Line Display 32 K Message
Memory
2706–E23J32B1 2706–E23J32
Four Line Display 32 K Message
Memory
2706–E43J32B1 2706–E43J32
Four Line Display 64 K Message
Memory
2706–E43J64B1 2706–E43J64
Four Line Display 128 K Message
Memory
2706–E43J128B1 2706–E43J128
The following keyboards are compatible with the DL40 Message Display.
Table 2.H
Applicable keyboards for use with the DL40 Message Display
Catalog No. Description
6120 & 6121
Allen-Bradley industrial computer standard
keyboards
1784-T50 Allen-Bradley industrial terminal keyboard
1784-T60 Allen-Bradley industrial terminal keyboard
IBM-PC or compatible -XT, -AT standard keyboard
IBM-PC or compatible -PC enhanced keyboard
NOTE: When used with the DL40, the Num Lock and Caps Lock indicators
will not illuminate. We recommend you use the 1784-T60 terminal keyboard
with Num Lock turned off.
Catalog Numbers
Compatible Keyboards
