Chapter 2
Introduction to the DL40
2 – 11
The following tables list the Allen-Bradley PLCs and computer interface
boards that are applicable for PassThrough file transfers with the DL40
message display over a DH+ link as of this printing.
Table 2.D
Applicable PLC types for PassThrough file transfers over DH+
PLC Types Series Revision
PLC-5/11 All All
PLC-5/15 B N or later
PLC 5/20 All All
PLC 5/25 A J or later
PLC 5/30 A B or later
PLC 5/40
A
B
E or later
PLC 5/60
A
B
B or later
PLC 5/80 All All
PLC 5/250 All All
Table 2.E
Applicable interface boards and modules for PassThrough file transfers over DH+
Catalog No. Description
1784-KT 1 /
2
-slot interface board
1784-KTX 1 /
2
-slot interface board
1784-KL Interface board for Allen-Bradley 1784-T45 or -T47
1784-KT2 Interface module for IBM PS2
1770-KF2 Serial to DH+ interface module
1784-PCMK PCMCIA interface board ➀
➀
Requires 2706-ND1 Series D Ver 3.0, which includes Interchange drivers.
The following table lists the Allen-Bradley PLCs that are applicable for
PassThrough file transfers with the DL40 message display over an Ethernet
link as of this printing.
Table 2.F
Applicable PLC types for PassThrough file transfers over Ethernet
PLC Types Series Revision
PLC 5/40E
A
B E or later
PLC 5/60E
A
B B or later
PLC 5/80E All All
PLC 5/250 All All
System Requirements for
Remote I/O PassThrough
Using DH+
System Requirements for
Remote I/O PassThrough
Using Ethernet
