Publication 2706-UM016D-EN-P - March 2006
4-22 InView Protocol
Transmission for Setting Time with AM/PM Format
Response: NONE
300 ms pause
2. Clear the message queue.
This transmission is used to remove the time that was just
loaded into the message queue.
Transmission:
Transmission for Clearing the Message Queue
Response: NONE
Set Time in Broadcast Mode with 24 Hour Format
This command is used to set the time and the format for the time in all
displays. This is primarily done using the automation software to
synchronize the time in the displays with the computer. This requires
two separate transmissions. First, set the time and format for the time.
Second, clear the queue. The following is an example of setting the
time to 1035 and the format for the time to be 24 hour (military)
format.
1. Set the time and time format.
Transmission:
ADDR Beginning of
Frame FUNC H.O.
ADDR
L.O.
ADDR
DATA EOF Ready to rec.
resp
: FF 01 00 64 ^AZ00^BE 1034^C^BE’S^C^D CR LF
TIP
See section InView Display Communication Protocol
Functions and Descriptions on for further
explanation of the InView sign protocol being used.
Beginning of
Frame ADDR FUNC H.O.
ADDR
L.O.
ADDR
DATA LRC
Error
EOF Ready
to rec.
resp
: FF 06 00 65 FFFF 98 CR LF
