Publication 2706-UM016D-EN-P - March 2006
4-48 InView Protocol
Special Function Command to Set Time and Time Format Continue
Command Code
Command Function
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Text ^B 02 Write Special Function E 45 Set Time (Sp) 20
Special Function Command to Set Time and Time Format Continued
Command Code (Continued)
Set Time
Set Hour and Minutes HhMm ASCII Hex Description ASCII Hex
HhMm 1034 (Example) 1034 31303334 End of Text ^C 03
HhMm 0945 (Example) 0945 30393435
H = ASCII digit for hours (10’s digit)
h = ASCII digit for hours (1’s digit)
M = ASCII digit for Minutes (10’s digit)
m = ASCII digit for Minutes (1’s digit)
Special Function Command to Set Time and Time Format Continued
Command Code
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Text ^B 42 Set Time Format AM/PM ‘S 2753 End of Text ^C 03
Set Time Format 24Hr (Military) ‘M 274D
Special Function Command to Set Time and Time Format Continued
Description ASCII Hex
End of Transmission ^D 04
