Publication 2706-UM016D-EN-P - March 2006
InView Protocol 4-51
Set Serial Address
This command will change a serial address for a display.
Text Position Placement
Allen-Bradley uses the 2706-P42, 2706-P44, and 2706-P72 series
displays with InView industrial protocol. The displays can be single
line, two-line or 3-line. Displaying of messages using protocol is
slightly different based on which display is being used.
Below are some rules for the 2706-P44 and 2706-P72 display. The
2706-P42 display ignores the display position and show (display) the
text.
Special Function Command to Set Serial Address
Type Code Display Address
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Header ^A 01 All displays Z 5A Display Address 01-FF 3031-4646
Special Function Command to Set Serial Address Continued
Command Code
Command Function
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Text ^B 02 Write Special Function E 45 Set address 7 37
Special Function Command to Set Serial Address Continued
Command Code (Continued)
Serial address ASCII Hex Description ASCII Hex
New serial address 01-FE 3031-4645 End of Transmission ^D 04
