Publication 2706-UM016D-EN-P - March 2006
InView Protocol 4-47
Set Time
Time can be set in either AM/PM format or 24 hour (military) format.
The following shows the valid values for this command
Special Function Command to Set Memory Size
Type Code Display Address
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Header ^A 01 All displays Z 5A Display
Address 00 3030
Special Function Command to Set Memory Size Continued
Command Code
Command Function
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Text ^B 02 Write Special Function E 45 Set Message
Size a 61
Special Function Command to Set Memory Size Continued
Command Code (Continued)
Description ASCII Hex Description ASCII Hex
Message Size (minimum) 50 Bytes 0032 30303332 End of Transmission ^D 04
Message Size (maximum) 450 Bytes 01C2 30314332
Special Function Command to Set Time and Time Format
Type Code Display Address
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Header ^A 01 All displays Z 5A Display
Address 00 3030
