Publication 2706-UM016D-EN-P - March 2006
InView Protocol 4-9
Or
Remove a Message on a Specific Display
The following removes message 367 on a display address 4.
Remove a Message on s Specific Display
Examples of the Control-V
Function This function allows for the updating of variables that are embedded
in messages. If no display address is used, it updates all displays with
the variable data. The following example updates variable 0 in all
displays.
Update a Variable on all Displays
Update variable 0 with the value of 2395 on all displays
Update a Variable on all Displays
Or
Name [CTRL][T] MSG # Backslash Function Backslash Display
address Return
ASCII ^T 4095 \ 1 \ 24 ^M
Hex \14 \34\30\39\35 \5C \31 \5C \32\34 \0D
Name [CTRL][T] MSG # Backslash Function Backslash Display
address Return
ASCII ^T 367 \ 3 \ 4 ^M
Hex \14 \33\36\37 \5C \33 \5C \34 \0D
Name [CTRL][V] Variable Data Return
ASCII ^V 2395 ^M
Hex \16 \32\33\39\35 \0D
Name [CTRL][V] Variable Data Backslash Variable # Return
ASCII ^V 2395 \ 0 ^M
Hex \16 \32\33\39\35 \5C \30 \0D
