2706-p22r specifications – Rockwell Automation 2706-P42_P43_P44_P72_P74_P92_P94 InView Marquee Message Display User Manual User Manual
Page 137

Publication 2706-UM016D-EN-P - March 2006
Specifications A-3
2706-P22R Specifications
Display Load 2706-P9x
100% Condition - All display pixels are lit in amber.
Usage - Highly unlikely, use this value for sizing input power circuit.
50%
Condition - 50% of the display lit in amber (screen full of 32 pixel amber ‘B’s).
Usage - Unlikely, not a typical display condition, may be seen with use of bitmaps.
25%
Condition - Mixture of red, green and amber characters and spaces.
Usage - Typical display load for most message types.
Display Characters
Attribute
Value
Character Height Two line display
17.8 mm (0.7 in.)
Character Set English
Standard and Extended ASCII Characters
Characters per Display Line
20
Viewing Distance, Approx.
7.6 m (25 ft)
Character Type
Red LED Indicator
Electrical
Attribute
Value
Input Voltage
18 … 30V dc, 0.5 A at 18V dc
Input Power
10 Watts
Fuse Type
Fast Acting Littel fuse series 217, or equivalent,
1.6 A
Battery
Lithium
(1)
(1)
Refer to publication AG.5-4 for battery disposal information.
Serial Communications
Attribute
Value
Electrical Interface
RS-232 (EIA-/TIA-232-E)
RS-485 (EIA-485)
Communication Rate
9600
