Publication 2706-UM016D-EN-P - March 2006
4-42 InView Protocol
for each of the fields shown above. Each of these are concatenated
together to make up the InView message.
InView Message Format
Type Code Display Address
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Header ^A 01 All displays Z 5A Display
Address 00 3030
InView Message Format Continued
Command Code
Command Priority
Description ASCII Hex Description ASCII Hex Description ASCII Hex
Start of Text ^B 02 Write Text file A 41 Low 0 30
Write Special Function
E
(1) 45 Medium 1 31
High 2 32
(1) Refer to Trigger a Message on a Specific Display using Priority Messaging on page 6 for further explanation of the Special Function command
InView Message Format Continued
Command Code (Continued) Message Control
Message # Display Position
Description ASCII Hex Description ASCII Hex Description ASCII Hex
0001 001 303031 Start of Mode Field ^[ 1B Middle (space) 20
Through Top “ 22
4000 FA0 464130 Bottom & 26
4095 FFF 464646 Fill 0 30
