Page 96

Publication 1763-UM001D-EN-P - March 2011

94 Communication Connections

Safety Considerations

This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D or
non-hazardous locations only.

See Safety Considerations on page 21

for additional information.

Install and Attach the AIC+

1. Take care when installing the AIC+ in an enclosure so that the cable

connecting the MicroLogix™ controller to the AIC+ does not interfere
with the enclosure door.

2. Carefully plug the terminal block into the RS-485 port on the AIC+ you

are putting on the network. Allow enough cable slack to prevent stress
on the plug.

3. Provide strain relief for the Belden cable after it is wired to the terminal

block. This guards against breakage of the Belden cable wires.

WARNING

EXPLOSION HAZARD

AIC+ must be operated from an external power
source.

This product must be installed in an enclosure. All
cables connected to the product must remain in the
enclosure or be protected by conduit or other
means.
