Publication 1763-UM001D-EN-P - March 2011
164 Specifications
EFT/B immunity
For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-4: 2 kV, 5 kHz on signal ports
For all other modules
IEC1000-4-4: 2 kV, 5 kHz
Surge transient immunity
For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-5: 2 kV common mode, 1 kV differential mode
For all other modules
IEC1000-4-5: 2 kV common mode, 1 kV differential mode
Conducted RF immunity
For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-6: 10V, 0.15…80 MHz
(2)
For all other modules:
IEC1000-4-6: 10V, 0.15…80 MHz
(2)
(1) Refer to the module’s Installation Instruction for exact operating temperature range.
(2) Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range is 30…1000 MHz.
General Specifications
Specification
Value
Input Specifications
Specification
1762-IA8
1762-IQ8
1762-IQ16
1762-IQ32T
1762-IQ8OW6
Shipping weight,
approx. (with carton)
209 g (0.46 lbs.)
200 g (0.44 lbs.)
230 g (0.51 lbs.)
200g (0.44 lbs.)
280g (0.62 lbs.)
Voltage category
100/120V AC
24V DC
(sink/source)
(1)
24V DC
(sink/source)
(1)
24V DC
(sink/source)
(1)
24V DC
(sink/source)
(1)
Operating voltage
range
79V AC…132V AC
at 47 Hz…63 Hz
10…30V DC at
30 °C (86 °F)
10…26.4V DC at
55 °C (131 °F)
10…30V DC
10…26.4V DC
(2)
10…30V DC
(24 points) at 30 °C
(86 °F)
10…26.4V DC
(23 points)at 60 °C
(140 °F)
10…30V DC at
30 °C (86 °F)
10…26.4V DC at
65 °C (149 °F)
Number of inputs
8
8
16
32
8
Bus current draw, max.
50 mA at 5V DC
(0.25W)
50 mA at 5V DC
(0.25W)
70 mA at 5V DC
(0.35W)
(3)
170 mA at 5V DC
0 mA at 24V DC
110 mA at 5V DC
80 mA at 24V DC
Heat dissipation, max.
2.0 W
3.7 W
4.3 W at 26.4V
5.4 W at 30V
5.4 W at 26.4V DC
6.8 W at 30V DC
5.0 W at 30V DC
4.4 W at 26.4V DC
(The Watts per
point, plus the
minimum W, with
all points
energized.)
Signal delay, max.
On delay: 20.0 ms
Off delay: 20.0 ms
On delay: 8.0 ms
Off delay: 8.0 ms
On delay: 8.0 ms
Off delay: 8.0 ms
On delay: 8.0 ms
Off delay: 8.0 ms
On delay: 8.0 ms
Off delay: 8.0 ms
Off-state voltage, max.
20V AC
5V DC
5V DC
5V DC
5V DC
Off-state current, max.
2.5 mA
1.5 mA
1.5 mA
1.0 mA
1.5 mA
