Changing mode switch position – Rockwell Automation 1763 MicroLogix 1100 Programmable Controllers User Manual User Manual
Page 127

Publication 1763-UM001D-EN-P - March 2011
Using the LCD 125
Changing Mode Switch Position
Mode Switch position can be changed at two different times using LCD
keypad. One is when the controller is powered up, and the other is while the
controller is powered on.
Mode Switch position can be set to either PROG or RUN when the controller
is powered up. This allows the controller operation which is different from the
previous mode, that is, any program under RUN before can be stopped or any
new program can be run when the controller is powered up.
•
How to forcibly set Mode Switch to RUN when the controller is
powered up
Press OK key for 5 seconds when the controller is powered up. The
following LCD screen appears if it’s successfully done.
Possible Controller Modes by Mode Switch Position
When the Mode Switch
Positions at
Possible Controller Modes are
PROGRAM
download in progress
program mode
suspend mode
(operation halted by execution of the SUS instruction)
REMOTE
remote download in progress
remote program mode
remote suspend mode
(operation halted by execution of the SUS instruction)
remote run mode
remote test continuous mode
remote test single scan mode
RUN
run mode
