Rockwell Automation 1763 MicroLogix 1100 Programmable Controllers User Manual User Manual
Page 179

Publication 1763-UM001D-EN-P - March 2011
Specifications 177
Thermocouple E (-270…-210 °C [-454…-346 °F])
±4.2 °C [±7.6 °F]
±6.3 °C [±11.4 °F]
±0.2698 °C/ °C [±0.2698 °F/ °F]
Thermocouple R
±1.7 °C [±3.1 °F]
±2.6 °C [±4.7 °F]
±0.0613 °C/ °C [±0.0613 °F/ °F]
Thermocouple S
±1.7 °C [±3.1 °F]
±2.6 °C [± 4.7 °F]
±0.0600 °C/ °C [±0.0600 °F/ °F]
Thermocouple C
±1.8 °C [±3.3 °F]
±3.5 °C [±6.3 °F]
±0.0899 °C/ °C [±0.0899 °F/ °F]
Thermocouple B
±3.0 °C [±5.4 °F]
±4.5 °C [±8.1 °F]
±0.1009 °C/ °C [±0.1009 °F/ °F]
±50 mV
±15
μ
V
±25
μ
V
±0.44
μ
V/ °C [±0.80
μ
V/ °F]
±100 mV
±20
μ
V
±30
μ
V
±0.69
μ
V/ °C [±01.25
μ
V/ °F]
(1) The module uses the National Institute of Standards and Technology (NIST) ITS-90 standard for thermocouple linearization.
(2) Accuracy and temperature drift information does not include the affects of errors or drift in the cold junction compensation circuit.
(3) Accuracy is dependent upon the analog/digital converter output rate selection, data format, and input noise.
(4) Temperature drift with autocalibration is slightly better than without autocalibration.
1762-IT4 Accuracy
Input Type
(1)
With Autocalibration Enabled
Without Autocalibration
Accuracy
(2)
(3)
for 10 Hz, 50 Hz and
60 Hz Filters (max.)
Maximum Temperature
Drift
(2)
(4)
at 25 °C [77 °F]
Ambient
at 0…60 °C
[32…140 °F]
Ambient
at 0…60 °C [32…140 °F]
Ambient
TIP
For more detailed 1762-IT4 accuracy information, see
publication 1762-UM002.
Output Specifications
Specification
1762-IF2OF2
1762-OF4
Number of outputs
2 single-ended (unipolar)
4 single-ended (unipolar)
Update time (typical)
4.5 ms
D/A converter type
Resistor string
R-2R Ladder Voltage Switching
Resistive load on current output
0…500
Ω
(includes wire resistance)
0…500
Ω
(includes wire resistance)
Load range on voltage output
> 1K
Ω
> 1K
Ω
Reactive load, current output
< 0.1 mH
< 0.1 mH
Reactive load, voltage output
< 1
μ
F
< 1
μ
F
Typical overall accuracy
(1)
±1.17% full scale at -20...65 °C
(2)
±0.5% full scale at 25 °C
±1.17% full scale at -20...65 °C
±0.5% full scale at 25 °C
Output ripple range 0…500 Hz
(referred to output range)
< ±0.1%
< ±0.1%
