Surge current per point:
•peak current
•maximum surge duration
•maximum rate of repetition at 30 °C (86 °F)
•maximum rate of repetition at 55 °C (131 °F)
•4.0 A
•10 ms
•once every second
•once every 2 seconds
•Not applicable
•Not applicable
•Not applicable
•Not applicable
Turn-on time, max.
0.1 ms
6 µs
Turn-off time, max.
1.0 ms
18 µs
Repeatability, max.
n/a
2 µs
Drift, max.
n/a
1 µs per 5 °C (9 °F)
(1) Output 2 and 3 are designed to provide increased functionality over the other FET outputs. Output 2 and 3 may be used like the other FET transistor outputs, but in addition,
within a limited current range, they may be operated at a higher speed. Output 2 and 3 also provide a pulse train output (PTO) or pulse width modulation output (PWM)
function.
BBB FET Output Specifications
Description
General Operation
High Speed Operation
(1)
(Output 2 and 3 Only)
AC Input Filter Settings
Nominal Filter Setting (ms)
ON Delay (ms)
OFF Delay (ms)
Minimum Maximum
Minimum Maximum
8
2
20
10
20
High-Speed DC Input Filter Settings (Inputs 0 to 3)
Nominal Filter Setting (ms) ON Delay (ms)
OFF Delay (ms)
Maximum Counter Frequency (Hz)
50% Duty Cycle
Minimum Maximum
Minimum Maximum
00125
0.005
0.0125
0.003
0.0085
40.0 kHz
(2)
0.025
0.005
0.025
0.005
0.025
20.0 kHz
0.075
0.040
0.075
0.045
0.075
6.7 kHz
0.100
0.050
0.100
0.060
0.100
5.0 kHz
0.250
0.170
0.250
0.210
0.250
2.0 kHz
0.500
0.370
0.500
0.330
0.500
1.0 kHz
1.00
0.700
1.000
0.800
1.000
0.5 kHz
2.000
1.700
2.000
1.600
2.000
250 Hz
4.000
3.400
4.000
3.600
4.000
125 Hz
8.000
(1)
6.700
8.000
7.300
8.000
63 Hz
16.000
14.000
16.000
14.000
16.000
31 Hz
(1) This is the default setting.
(2) OS Series B FRN4 or later
