Rockwell Automation 1763 MicroLogix 1100 Programmable Controllers User Manual User Manual
Page 163

Publication 1763-UM001D-EN-P - March 2011
Specifications 161
Standard DC Input Filter Settings (Inputs 4 and higher)
Nominal Filter Setting (ms)
ON Delay (ms)
OFF Delay (ms)
Maximum Frequency (Hz)
50% Duty Cycle
Minimum Maximum
Minimum Maximum
0.500
0.090
0.500
0.020
0.500
1.0 kHz
1.000
0.500
1.000
0.400
1.000
0.5 kHz
2.000
1.100
2.000
1.300
2.000
250 Hz
4.000
2.800
4.000
2.700
4.000
125 Hz
8.000
(1)
5.800
8.000
5.300
8.000
63 Hz
16.000
11.000
16.000
10.000
16.000
31 Hz
(1) This is the default setting.
Relay Contact Ratings
Maximum Volts
Amperes
Amperes
Continuous
(1)
Volt-Amperes
Make
Break
Make
Break
240V AC
15.0 A
1.5 A
5.0 A
(2)
/3.0 A
3600 VA
360 VA
120V AC
30.0 A
3.0 A
5.0 A
(2)
/3.0 A
3600 VA
360 VA
125V DC
0.22 A
(3)
1.0 A
28 VA
24V DC
1.2 A
(3)
2.0 A
(1) 5.0 A for UL 508
3. 0A for UL 1604, Class 1, Division 2, Hazardous Locations, Groups A, B, C, D
(2) 3.0 A above 40 °C.(104 °F)
(3) For DC voltage applications, the make/break ampere rating for relay contacts can be determined by dividing 28 VA by
the applied DC voltage. For example, 28 VA/48V DC = 0.58A. For DC voltage applications less than 14V, the
make/break ratings for relay contacts cannot exceed 2A.
Working Voltage (1763-L16AWA)
Description
1763-L16AWA
Power supply input to backplane isolation Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s
265V AC Working Voltage (IEC Class 2 reinforced insulation)
Input group to backplane isolation
Verified by one of the following dielectric tests:1517V AC for 1 s or 2145V DC for 1 s
132V AC Working Voltage (IEC Class 2 reinforced insulation)
Input group to input group isolation
Verified by one of the following dielectric tests:1517V AC for 1 s or 2145V DC for 1 s
132V AC Working Voltage (basic insulation)
Output group to backplane isolation
Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s
265V AC Working Voltage (IEC Class 2 reinforced insulation)
Output group to output group isolation
Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1s
265V AC Working Voltage (basic insulation) 150V AC Working Voltage (IEC Class 2 reinforced
insulation).
