7–2 Communication Commands
Publication 1770Ć6.5.16 - October 1996
Use this table to locate commands you want to use. For additional
information on the commands, refer to the specified pages.
!
ATTENTION: Using command codes not listed will
produce unpredictable results.
Command CMD FNC Processors Page
MicroĆ
Logix
1000
SLC
500 SLC
5/03 SLC
5/04 1774Ć
PLC
PLCĆ2 PLCĆ3 PLCĆ5
PLCĆ5
/250 PLCĆ5/
VME
apply port configuration 0F 8F 4 4 4 7-4
bit write 0F 02 4 ➄ 4 7-4
change mode
0F 3A 4 4 7-5
change mode
0F 80 4 4 7-5
close file 0F 82 4 4 4 4 7-5
diagnostic status 06 03 4 4 4 4 4 4 4 4 4 ➄ 7-6
disable forces 0F 41 4 4 4 4 4 ➄ 4 ➄ 7-6
disable outputs 07 00 4 7-6
download all request 0F 50 4 4 ➄ 4 7-7
download completed 0F 52 4 4 4 4 4 4 ➄ 4 7-7
download request 0F 05 4 7-8
echo 06 00 4 4 4 4 4 4 4 4 4 ➄ 7-8
enable outputs 07 01 4 7-9
enable PLC scanning 07 03 4 7-9
enter download mode 07 04 4 7-9
enter upload mode 07 06 4 7-10
exit download/upload mode 07 05 4 7-10
file read 0F 04 4 4 7-10
file write 0F 03 4 4 7-11
get edit resource 0F 11 4 4 4 4 4
➄
4 7-11
initialize memory 0F 57 4 4 4 4 4 ➄ 4 ➄ 7-12
modify PLCĆ2 compatibility
file
0F 5E 4 7-12
open file 0F 81 4 4 4 4 7-13
physical read
04 Â 4 4 7-13
physical read
0F 09 4 7-13
physical write 0F 08 4 7-14
protected bit write 02 Â 4 4 4 4 4 7-15
protected typed file read 0F A7 4 4 4 4 7-16
À This command cannot be executed by channel 0 of a PLCĆ5/11, Ć5/20, Ć5/30, Ć5/40, Ć5/60, or Ć5/80 processor.
Á The following processors can initiate these commands but cannot respond to them:
Processor Series/Revision
Processors:
Series A / revision M PLCĆ5/40, Ć5/40L, Ć5/60, Ć5/60L
Series A / revision J PLCĆ5/30
Series A / revision H PLCĆ5/11, Ć5/20
Series B / revision J PLCĆ5/40, Ć5/40L, Ć5/60, Ć5/60L
Series C / revision G PLCĆ5/11, Ć5/20, Ć5/20E, Ć5/30, Ć5/40, Ć5/40L, Ć5/V40, Ć5V40L, Ć5/60, Ć5/60L, Ć5/80, Ć5/80E, Ć5/V80
 This command has no FNC byte.
à SLC 500 refers to any SLC 500, SLC 5/01, SLC 5/02, SLC 5/03, or SLC 5/04 processor.
➄ Receive only. Processors with this note cannot send the command; they receive the command from a computer.
