7–16 Communication Commands
Publication 1770Ć6.5.16 - October 1996
protected typed file read
Reads data from an open file in a MicroLogix 1000 or an SLC 500
processor.
C
CMD
0F STS
TNS
R STS TNS
CMD
4F
DST SRC
SRC DST
FNC
A7
File
Type Tag Offset
DATA
Size
Offset is the word offset into the file (low byte, then high byte).
Size is the size of data to read:
For this processor Valid range for Size (in bytes)
MicroLogix 1000 0Ć248
SLC 500, SLC 5/01, SLC 5/02 0Ć96
SLC 5/03 SLC 5/04
0Ć225 with internet protocol
SLC 5/03, SLC 5/04
0Ć236 without internet protocol
protected typed file write
Writes data to an open file in a MicroLogix 1000 or an SLC
processor. For MicroLogix 1000 processors, this command can be
used to update the Terminal ID by writing two bytes. (To do this,
size = 02h, the tag = 4176, the offset = 0000, the file type = 90, and
the two bytes of data contain the terminal ID, low byte first.)
C CMD
0F STS
TNS
R STS TNS
CMD
4F
DST SRC
SRC DST
FNC
AF
File
Type Tag Offset Size Data
EXT
STS
Offset is the word offset into the file (low byte, then high byte).
Size is the size of data to read:
For this processor Valid range for Size (in bytes)
MicroLogix 1000 0Ć241
SLC 500, SLC 5/01, SLC 5/02 0Ć89
SLC 5/03 SLC 5/04
0Ć218 with internet protocol
SLC 5/03, SLC 5/04
0Ć229 without internet protocol
• MicroLogix 1000
• SLC 500
• SLC 5/03
• SLC 5/04
• MicroLogix 1000
• SLC 500
• SLC 5/03
• SLC 5/04
