8–4 Message Packet Status Codes (STS, EXT STS)
Publication 1770Ć6.5.16 - October 1996
EXT STS Codes for CMD 0F
Hex Code Explanation
0 Not used
1 A field has an illegal value
2 Less levels specified in address than minimum for any address
3 More levels specified in address than system supports
4 Symbol not found
5 Symbol is of improper format
6 Address doesn't point to something usable
7 File is wrong size
8 Cannot complete request, situation has changed since the start of the
command
9 Data or file is too large
A Transaction size plus word address is too large
B Access denied, improper privilege
C Condition cannot be generated Ć resource is not available
D Condition already exists Ć resource is already available
E Command cannot be executed
F Histogram overflow
10 No access
11 Illegal data type
12 Invalid parameter or invalid data
13 Address reference exists to deleted area
14 Command execution failure for unknown reason; possible PLCĆ3
histogram overflow
15 Data conversion error
16 Scanner not able to communicate with 1771 rack adapter
17 Type mismatch
18 1771 module response was not valid
19 Duplicated label
22 Remote rack fault
23 Timeout
24 Unknown error
1A File is open; another node owns it
1B Another node is the program owner
1C Reserved
1D Reserved
1E Data table element protection violation
1F Temporary internal problem
These codes are for passthru from a
DH+ link to a remote I/O link.
